Starting at $1,095.00CAD

0024-85 Fyrite InTech Combustion Analyzer

Name: 0024-85 Fyrite InTech Combustion Analyzer
SKU: placeholder-fyrite-intech-combustion-analyzer
Price: 1095.00 CAD
Availability: InStock

For entry-level & residential technicians who need to ensure safe operating conditions & determine combustion efficiency

Starting at

$1,095.00CAD

Have questions? We're here to help!

Call

Configure

Used in

Also found in

Fyrite In Tech Combustion Analyzer 02750

The InTech® combustion analyzer is the perfect tool for entry-level and residential technicians who need to ensure safe operating conditions and determine combustion efficiency. The InTech® features 6 fuels in the North American configuration to suit a wide variety of applications.

The InTech® includes sensors for O2 and CO, with an option for an external NOx filter. The CO sensor can be replaced in the field without down time using pre-calibrated sensors. The InTech® calculates values like efficiency, CO2 and CO air-free to help monitor combustion processes effectively and accurately.

• All-in-one instrument makes combustion tuning fast and simple with readings for O2, CO, CO2, combustion efficiency, and temperature

• Combustion App allows users to quickly create custom reports with comments and send via email (available for Android & iOS)

• Automatic sensor protection helps technicians protect the analyzer in harsh environments, extending sensor life

• Ambient CO monitoring function allows technicians to check for dangerous CO levels

• Quick and easy sensor replacement in the field reduces downtime and doesn’t require calibration gas

Measurements	O₂: 0 to 20.9% CO: 0 to 2000 ppm Stack temperature: -4 to 1202 °F (-20 to 650 °C) Ambient air temperature: -4 to 212 °F (-20 to 100 °C)
Display	2.7 in. (69 mm) monochrome LCD w/backlight
Power	4x AA batteries
Run Time	15 hours minimum (alkaline batteries)
Size (H x W x D)	8.0 x 3.6 x 2.3 in. (20.3 x 9.1 x 5.8 cm)
Weight	1 lb. (0.45 kg) including batteries
Fuels[1]	Natural gas, oil 2/6, kerosene, propane, butane, LPG, B5, KOKS, LEG, biofuel
Operating Conditions	23 to 113 °F (-5 to 45 °C), 15 to 90% RH (non-condensing), 1 ATM ± 10%
Warm-up Time	30 to 60 seconds
Memory	10 locations
Communications	USB 2.0 (mini-B), IrDA
Approvals	CE mark, EN 50379-1 & -3
Warranty	2 years (including sensors)
[1] Depending upon combustion equation setting (North American or Siegert) – see manual for details
Sensors:	Up to 2
Measuring Range:	0 to 20.9% 0 to 2000 ppm
Stack Temperature:	-4 to 1202 °F (-20 to 650 °C)
User Interface:	Monochrome LCD w/Backlight
Display Size:	2.7 in. (69 mm)
Power:	4 × Alkaline Batteries
Run Time:	15 Hours (Alkaline Batteries)
Warm-Up Time:	30 to 60 seconds
Digital Communications:	USB 2.0 (mini-B), IrDA
Ambient Temperature:	23 to 113 °F (-5 to 45 °C)
Humidity:	15 to 90% RH (non-condensing)
Altitude:	1 ATM ± 10%
Product Dimensions (L×W×H):	8" × 3.6" × 2.3" (20.3 × 9.1 × 5.8 cm)
Product Weight:	1 lb. (0.45 kg) including batteries
Fuel Equations:	Natural gas, oil 2/6, kerosene, propane, butane, LPG, B5, KOKS, LEG, biofuel
Approvals:	CE, EN 50379-1 , EN 50379-3
Internal Memory:	10 Records
Warranty:	2 Years (including sensors)
Printer:	IrDA + Bluetooth Printer (Optional)
