HBM Z6 Stainless Steel, Single-Ended Beam Load Cell

HBM Z6 Stainless Steel, Single-Ended Beam Load Cell

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
HBM Z6 Stainless Steel Single Ended Beam Load Cell 10938

 Featuring stainless steel and a welded seal, this bending beam load cell is ideal for harsh or caustic environments and washdown applications. Capacities range from 5 kg to 200 kg. Complete with 10 ft of load cell cable.

ApprovalsFM
OIML
Ex (available upon request)
WarrantyOne-year limited
Cable Color CodeBlue +Excitation
Black –Excitation
White +Signal
Red –Signal
Green +Sense
Grey –Sense
Cable Diameter0.190 in
PVC jacket
Cable Length10 ft
Insulation Resistance5,000 megohm
Combined Error0.05% full scale
Rated Excitation5 to 10 V DC (15 V maximum)
Safe Overload150% full scale
Seal TypeWelded-seal, IP68
TemperatureOperating range
0 °F to 150 °F (-18 °C to 65 °C)
Material/FinishStainless steel
Input Resistance350 to 400 ohm
Output Resistance356 ohm
Full Scale Output2.0 mV/V
  • Thumbnail of document Data Sheet - HBM Z6 Stainless Steel, Single-Ended Beam Load Cell
    Download

    Data Sheet - HBM Z6 Stainless Steel, Single-Ended Beam Load Cell

    Download
