HF In-Line Flow Monitors
For air, water or caustic fluids, with ± 2% FS, unrestricted mounting, and high temperature and pressure options
The Series HF In-Line Flow Monitors are ruggedly constructed and ideal for direct measurement for a range of compatible gases, oil or water based liquids. This Series is designed based on a floating orifice disk and variable area flow measurement. Flowing media forces linear motion of the orifice disk and a ring shaped magnet which ride on a tapered center shaft. The transfer magnet drives a clearly visible magnet follower located outside the flow tube, and a ring on the magnet follower indicates flow rate on the direct reading scale.
• Setting pressure relief valves
• Fluid handling equipment
• Detecting low-flow rates for lubricating liquids
• Pulp and paper
• Industrial maintenance
• Fluid power
• Heating loop flow
