Starting at $1,080.00CAD

IRU-2420 25 ft Mid Range Ultrasonic Level Sensor

Name: IRU-2420 25 ft Mid Range Ultrasonic Level Sensor
SKU: placeholder-iru-2420-25-ft-mid-range-ultrasonic-level-sensor
Price: 1080.00 CAD
Availability: InStock

Provides a non-contact method of detecting level, presence/absence detection, volume, proximity & distance, CSA approved, Class 1, Div. 2

Starting at

$1,080.00CAD

Have questions? We're here to help!

Call

Configure

Used in

IRU 2420 25 ft Mid Range Ultrasonic Level Sensor 05964

Designed with flexibility in mind. The IRU-2420 features our AutoSense software for quick and easy programming in a variety of application settings.

Hazardous Location Certified
IRU-2420 ultrasonic sensors are suitable for hazardous locations classified under CSA Class 1, Div. 2.

Flexible Programming
This series of ultrasonics was designed with flexibility in mind. It features our AutoSense software for quick and easy programming in a variety of application settings.

A Good Fit
With a 25 ft. range, a 2 in. NPT fitting, and a 4-20mA output, the IRU-2420 sensors work well for many tank level applications.

• AutoSense Software for hassle-free setup
• Internal Temperature Compensation
• Works on solids and liquids

Operating Range	1 - 25 ft. (0.3 - 7.6 m)
Beam Pattern	9º off axis
Frequency	69 kHz
Accuracy	±0.25% of detected range
Resolution	0.1 in. (2.5 mm)
Response Time	Programmable (20 ms minimum)
Connectivity
Output	4-20 mA -600 ohms @ 24 VDC -150 ohms @ 12 VDC • 4-20 mA with (2) NPN outputs
Environmental
Ratings	IP65
Operating Temperature	-40º - 140ºF (-40º - 60ºC)
Electrical
Total Current Draw	75 mA @ 24 VDC
Supply Voltage	12-28 VDC
Wring Connection	4 or 5 conductor shielded cable
Programming
Interface With RST-3001/3002 Programmer	-The RST-3001 is 32 bit only -The RST-3002 is 32 and 64 bit compatible
Physical	• PVDF (Kynar®) transducer housing • PC/PET upper housing • Transducer Type: Ceramic, PVDF faced
Certification	• Class 1, Div. 2, Groups A, B, C, D • IP65
