IRU-9400 High Sensivity Ultrasonic Level Sensor

Name: IRU-9400 High Sensivity Ultrasonic Level Sensor
SKU: placeholder-iru-9400-high-sensivity-ultrasonic-level-sensor
Price: 822.00 CAD
Availability: InStock

Indoor sensor with a more sensitive transducer to detect difficult targets such as reflective and soft surfaces

Starting at

$822.00CAD

Have questions? We're here to help!

Call

Configure

Used in

IRU 9400 High Sensivity Ultrasonic Level Sensor 05968

Versatile Range
The IRU-9400 ultrasonic handles targets at distances from 6 in. to 35 ft. Measure a larger range without complex mounting arrangements.

Sensitive Transducer
This sensor uses a more sensitive transducer to detect difficult targets. It’s great for non-reflective and/or soft surfaces. At the same time, it is not sealed for harsh environments and is recommended for use indoors and away from dust.

Object Detection
With the more sensitive transducer and superior range, the IRU-9400 is well suited for object detection applications.

• Easily configured for obstacle detection applications
• Internal Temperature Compensation
• Works on solids and liquids

Operating Range	0.50 - 35 ft. (0.15 - 10.67 m)
Beam Pattern	9º off axis
Frequency	50 kHz
Accuracy	±0.25% of detected range
Resolution	0.1 in. (2.5 mm)
Response Time	Programmable (20 ms minimum)
Connectivity
Output	• 4-20 mA • 4-20 mA with (2) NPN outputs • 0-2.5 V/0-5 V (selectable via software)
Environmental
Ratings	NEMA 12
Operating Temperature	-40º - 140ºF (-40º - 60ºC)
Electrical	75 mA @ 24 VDC
Supply Voltage	12-28 VDC
Wiring Connection	4, 5 or 8 conductor shielded cable
Programming
Interface with RST-3001 Programmer	-The RST-3001 is 32 bit only -The RST-3002 is 32 and 64 bit compatible
Physical	• PC/PET upper housing • PC/PET Blend Transducer
Certification	CSA General Purpose
