ITS-90 Mini Fixed-Point Cells

Name: ITS-90 Mini Fixed-Point Cells
SKU: placeholder-its-90-mini-fixed-point-cells
Price: 9436.00 CAD
Availability: InStock

The least expensive, easiest-to-use fixed-point standards available

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!

Call

Also found in

If cuteness were reason enough to buy a product, Fluke Calibration's Mini Fixed-Point Cells would win you over easily. But there’s a much better reason to buy them: they give you the least expensive, easiest-to-use fixed-point standards for your lab.

Mini cells eliminate the need for comparison calibrations. Temperatures of fixed-point cells are constant and intrinsic, so only the electrical parameters of the sensor under calibration need to be read. If you’re calibrating industrial thermometers, thermocouples, or thermistors and want the most accurate calibration possible, these mini cells will give it to you. If you need a wide range of temperatures, mini cells cover the triple point of water (0.01°C) and every ITS-90 point from indium (156.5985°C) to copper (1084.62°C).

• Lower uncertainties than comparison calibrations
• All ITS-90 fixed points from TPW to copper
• Reduced equipment and annual recalibration costs

Model Number	Fixed- Point	Temperature (°C)	Outside Diameter	Inside Diameter	Total Cell Height	Immersion Depth¹	Cell Only²	Simple Realization²
5901B-G	Water T.P.	0.01	30 mm	8 mm	170 mm	117 mm	0.2	0.5
5914A	Indium F.P.	156.5985	43 mm	8 mm	214 mm	140 mm	1.0	2.0
5915A	Tin F.P.	231.928
