Kaye
Kaye Thermocouple Feedthru
Feedthru fittings provide an easy way to seal the autoclave port when introducing thermocouples into pressure vessel penetrations
Feedthru fittings provide an easy way to seal the autoclave port when introducing thermocouples into pressure vessel penetrations.
Kaye feedthrus are machined from Stainless Steel and accommodate up to 18 thermocouples, or can be easily paired through a Y-adapter to provide capacity for up to 36 thermocouples. Silicone rubber seals are suitable for pressure and vacuum service.
• Accommodates from 1 to 18 thermocouples of any (or varying) diameter
• No threads or sharp edges to damage thermocouple wires
• No hole plugs required for unused t/c ports
• Accepts labeled thermocouples
• Simple and inexpensive silicone rubber sealing gaskets
• Standard 1.5" tri-clamp connections
• Easily installed with no tools required
• TUV certified for pressure vessels from -1 bar /+5 bar, and -60°C / + 160°C
Easy way to seal the autoclave port when introducing thermocouples into the chamber. Standard 1.5” TRICLAMP ® process connection. Installation is simple with out the need of any tools, fitted with safety release mechanism
