LCR55A Capacitance Tester

CR50A

LCR55A

Resistance

20 Ω, 200 Ω, 2 kΩ, 20 kΩ, 200 kΩ, 2 MΩ, 20 MΩ

20 Ω, 200 Ω, 2 kΩ, 20 kΩ, 2 MΩ, 20 MΩ

Capacitance

200 pF, 2000 pF, 2 µF, 20 µF, 200 µF, 2 mF, 20 mF

200 pF, 2000 pF, 2 µF, 20 µF, 200 µF, 2 mF

Inductance

-

200 µH, 2 mH, 200 mH, 200 H

Transistors

-

Hfe, Iceo (NPN, PNP)

Diodes

•

Std (3 V) & microwave oven (8 V)

Continuity Test

•

Display

3-1/2 digit LCD, max reading of 1999

Display Update Rate

2/s, nominal

2.5/s, nominal

Power

Standard 9 V transistor battery
