Lumiglas® Stainless Mini-Luminaire Series USL 01
Super-compact and offers a glare-free view through a sight glass
This super-compact sight glass luminaire is applicable for combination view/sight glass (single port version) or separate light and sight glass (dual-port version). This powerful super-compact size luminaire is designed to give glare-free illumination with sight glass styles as follows:
• Circular weld-on sight glass series DIN 28 120 starting at DN 25
• Circular sight glass series ANSI Bolt-On starting at 1″
• Visual Flow Indicators starting at size 1″
• Circular weld-neck series MV starting at DN 50
• Sanitary clamp connection series MetaClamp starting at 1/2”
• Mounting: bracket, wiper clip or sanitary clamp
• Light source: halogen or LED (ESL51)
• Power: 24V
• Housing: stainless steel, IP65
• Size: 24mm x 70mm
Ideal for lighting internals or small vessels such as bio reactors, laboratory mixers, filters, separators, pressure vessels, miniature tanks, pipelines and other normally enclosed systems in Non Ex hazardous areas.
Primarily intended for the Pharmaceutical, Bio-Tech and Food processing industries
