LumiStar3000™ LED Luminaire Series USL16/36 SS
World's brightest sight glass luminaire is 4x times brighter than a typical sight glass
LumiStar3000 is the world’s brightest sight glass luminaire: LED luminaire is 4x times brighter than a typical sight glass light, offering an unprecedented view of processes. Ultra-bright LED provides 3000 lumens at full brightness, four times the light output than a typical 100 W halogen light. The total internal reflection (TIR) lens with 23° beam angle, is ideal for vessel illumination through a sight glass with maximum light output and less than 5% loss of light output. The light is capable of continuous operation and emits cool white, 5500 K color temperature, optimized for stainless steel vessels. The light is designed for cool operation equipped with temperature-based current limiting and automatic dimming; over temperature shutdown. The LEDs have a long service life and are vibration and impact resistant. No heat radiation is directed into the process vessel (cold light output). The housing is available with a mounting bracket (USL16 Light) or a sanitary clamp connection (USL36 Light).
• 3000 lumens
• 4x as bright as a typical 100 W halogen light
• 10% the energy consumption: 40
• Washdown safe, NEMA 4X, IP65
• Capacitive switch, crevice-free
• Flashlight mode, intermittent, 9 dimmable settings, timer mode
• Programmable control: timer mode, remote operation
• Auto dimming prevents overheating
• Applications: pharmaceutical, 5000 to 7000-gallon size tanks and silos
Brightly illuminate process vessels for a clear view of processes in the chemical, pharmaceutical, bio-tech and food processing industries. It mounts on sight glass fittings for use in combined sight and light ports (single port version) or arranged separately (two port version). For illuminating bioreactors, mixers, filters and the interior of tanks, hoppers, silos, agitators, separators, pipelines and other – usually closed – containers in non-hazardous areas.
