M130 Thermocouple Calibrator

Name: M130 Thermocouple Calibrator
SKU: placeholder-m130-thermocouple-calibrator
Price: 1356.25 CAD
Availability: InStock

Handheld calibrator for measuring and sourcing thermocouples

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!

Call

The M130 Thermocouple Calibrator from Meriam Process Technologies combines form, fit and function to deliver precision measurement for field, plant or lab use. Each gauge includes protective red rubber boot, three (3) AA batteries, shorting plug and user’s manual.

Typical applications include temperature calibration, temperature verification and temperature measurement.

• Measure and source thermocouples
• Large, easy to read display with backlight
• Shirt pocket convenience
• Cold junction compensation
• T/C simulation (manual or auto)
• Three (3) programmable auto step routines (Units, T/C Type, LRV, URV, STEPS & DWELL TIME)
• Three (3) programmable auto ramp routines (Units, T/C Type, LRV, URV, STEPS UP/DOWN TIME, DELAY)
• Auto step simulation (0 - 100% or 25% increments) with definable LRV & URV

Accuracy	± 0.005% Reading ± 6 μV
Battery Type	Three (3) AA batteries
Battery Life	Over 100 hrs of continuous use
Connections	Standard mini-T/C connector
Engineering Unit Selection	Displays the temperature of a T/C in °C, °F, °R, K and mV
Thermocouple Types	Type B, E, J, K, N, R, S, T and mV
Storage Temperature	-40°C - 85°C (40°F - 185°F)
Operating Temperature	-10°C - 50°C (14°F - 122°F)
Materials	ESD dissipative polycarbonate
Weight	12 oz
Dimensions	6.0 in x 3.0 in x 1.0 in
Other Features	Backlight, record mode (up to 240 temperature measurements), auto shut off, low battery indication
Approvals / Certifications	CE Mark (standard), NIST Traceable Certificate with Data
