M200LS Smart Manometer

Name: M200LS Smart Manometer
SKU: placeholder-m200ls-smart-manometer
Price: 2325.00 CAD
Availability: InStock

Handheld, lab standard digital manometer with an NIST traceable accuracy of ± 0.01% of FS

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!

Call

Meriam’s M200LS Lab Standard Smart Manometer offers the best available pressure measurement accuracy in a portable, handheld format. Why LS? The M200LS features 60% better accuracy than our M200, and no temperature effects from 30°C - 50°C (59°C - 86°C). The NIST traceable accuracy is typically ± 0.01% of F.S. within the temperature range of 15°C - 30°C and ± 0.025% F.S. between -20°C - 15°C and 30°C - 50°C. Pressure ranges from 28 in H₂O F.S. to 500 PSIG F.S. are available.

M2 pressure sensors are available to measure gauge, differential, absolute or vacuum pressure. The display can read out in any of eleven pressure units or can be linearly scaled for special user units. An adjustable damping feature minimizes the effects of pulsating pressures.

A Min/Max function captures the extremes of pulsating or varying pressure signals and a Hold function can freeze the display at any point of interest. Auto Record documents up to 240 readings for future recall.

All models include a protective platinum boot, four (4) AA batteries, and a hard copy user's manual.

Note: M200LS model DN0028 (0 - 28.000 in H₂O, Differential) has ± 0.02% FS accuracy.

• Impressive accuracy of ± 0.01% full scale between 15°C - 30°C, ± 0.025% full scale between -20°C - 15°C and 30°C - 50°C
• Pressure ranges from 10 in H₂O F.S. to 3000 PSIG F.S. are available
• Numerous field, plant and lab applications, including leak testing and pressure drop monitoring
• Easy-to-use and designed to handle tough applications
• Auto record documents up to 240 readings for future recall
• Can be recalibrated in the field
• Measures various types of pressure, including differential, gauge, absolute and vacuum

Accuracy	± 0.010% F.S. from 15°C - 30°C ± 0.025% F.S. from -20°C - 15°C and 30°C - 50°C
Display	5 significant digit LCD (0.25 in high) 2 line x 16 alphanumeric characters with contrast adjustment. Two stage backlight with visual overrange indication.
Battery Type	Four (4) AA batteries
Battery Life	Over 100 hrs of continuous use
Process Connections	1/8 in female NPT, 316L SS
Media Compatibility	DN: Non-isolated differential sensor for clean, dry, non-corrosive gases GI & AI: Isolated Gauge or Absolute sensor for fluids compatible with 316L SS
Pressure Limits	28 in H_{2_{O, 200 in H_{2_{O, 2000 in H_{2_{O, 15 PSI, 30 PSI, 50 PSI, 100 PSI, 500 PSI, 900 mm Hg, 2000 mm Hg}}}}}}
Engineering Unit Selection	in of H₂O (select 4°C, 20°C, or 60°F), PSI, mm of Hg, in of Hg, mbar, bar, kPa, kg/cm², cm of H₂O and user selectable scaling
Storage Temperature	-40°C - 60°C (-40°F - 140°F)
Operating Temperature	15°C - 30°C (59°F - 86°F)
Base Unit Materials	Polycarbonate, permanently dissipative, ESD protection
Wetted Parts Materials	DN: 316L SS, brass, viton GI: 316L SS AI: 316L SS
Weight	14 oz
Dimensions	6.5 in x 3.6 in x 2.25 in
Other Features	Auto shut-off, auto record, field recalibration, leak test
Approvals / Certifications	NIST certificate with data included with all models
