Motor101A Data Logging System
Measures & records on & off status changes for motors or other equipment drawing up to 200 Amps
The Motor101A Includes:
(1) State101A: State Data Logger
(1) Current Switch
(1) IFC200: Interface Cable
The Motor101A was designed to measure and record the on/off status changes for motors or other equipment drawing up to 200 Amps.
Just clamp the Motor101A to a wire and when the current passing through exceeds 150 mA the output changes, providing a voltage for the Motor101A to measure. This device can hold up to 465,578 readings, but memory will only be used if the status has changed.
The Motor101A is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.
• No external power required
• 150 mA trip point
• Compatible up to 200 A
• Real-time operation
• Miniature size
• Reusable
• User-friendly
• Low cost
| General | |
| Memory | 465,578 readings |
| Reading Rate | 4 Hz to 1 every 24 hours |
| Baud Rate | 115,200 |
| LED Indicators | Red & Green |
| Push-Button Start | Yes |
| Battery Life | 10 years typical |
| Material | ABS Plastic |
| Dimensions | Data Logger: 1.4 in x 2.2 in x 0.6 in (36 mm x 56 mm x 16 mm) Current Switch: 2.1 in x 3.5 in x 1.0 in (54 mm x 89 mm x 16 mm) |
| Operating Environment | -15 °C to +40 °C (+5 °F to +104 °F), 10 %RH to 90 %RH non-condensing |
| Required Interface Package | IFC200 |
| Aprovals | CE |
| State | |
| State Resolution | 1 second (reading rate dependent) |
| Amperage Range | 0.15 to 200 Amps |
| Trip Point | 0.15 A (150 mA) fixed (200 mA AC for 50 Hz operation) |
| Status Output | N.O.1.0 A at 30 VAC/DC |
| Housing | Split Core |
• Energy audits
• Equipment monitoring
• Heating and cooling systems
• Fans
• Power supply on/off
• Monitoring gas, water or electric pumps
• Time studies
