MS Magnesense Differential Pressure Transmitter

Name: MS Magnesense Differential Pressure Transmitter
SKU: placeholder-ms-magnesense-differential-pressure-transmitter
Price: 184.07 CAD
Availability: InStock

An extremely versatile transmitter for monitoring pressure and air velocity

Starting at

$184.07CAD

Have questions? We're here to help!

Call

Configure

Used in

Also found in

MS Magnesense Differential Pressure Transmitter 02456

The Series MS Magnesense® Differential Pressure Transmitter is an extremely versatile transmitter for monitoring pressure and air velocity. This compact package is loaded with features such as: field selectable English or metric ranges, field upgradeable LCD display, adjustable dampening of output signal (with optional display) and the ability to select a square root output for use with Pitot tubes and other similar flow sensors.

Along with these features, the magnetic sensing technology provides exceptional long term performance and enables the Magnesense® transmitter to be the solution for a myriad of pressure and flow applications.

• Field selectable "English" or "Metric" ranges
• Field upgradeable LCD display
• Adjustable damping of output signal (with optional display)
• Ability to select a square root output for use with pitot tubes and other similar flow sensors

Service	Air and non-combustible compatible gases
Wetted Materials	Consult factory
Accuracy	± 1% for 0.25 in (50 Pa), 0.5 in (100 Pa), 2 in (500 Pa), 5 in (1250 Pa), 10 in (2 kPa), 15 in (3 kPa), 25 in (5 kPa); ± 2% for 0.1 in (25 Pa), 1 in (250 Pa) and all bidirectional ranges
Stability	± 1% FS/year
Temperature Limits	0°F - 150°F (-18°C - 66°C)
Pressure Limits	1 PSI maximum, operation; 10 PSI, burst
Power Requirements	10 VDC - 35 VDC (2-wire)
Output Signals	4 - 20 mA (2-wire)
Response Time	Field adjustable 0.5 s - 15 s time constant. Provides a 95% response time of 1.5 s - 45 s
Zero & Span Adjustments	Digital push button
Loop Resistance	Current output: 0 Ω - 1250 Ω max; Voltage output: min. load resistance 1 kΩ
Current Consumption	40 mA max
Display (optional)	4 digit LCD
Electrical Connections	4 - 20 mA, 2-wire: European Style Terminal Block for 16 AWG - 26 AWG
Electrical Entry	1/2 in NPS Thread. Accessory: Cable Gland for 5 mm - 10 mm diameter cable
Process Connection	3/16 in (5 mm) ID tubing. Maximum OD 9 mm
Enclosure Rating	NEMA 4X (IP66)
Mounting Orientation	Diaphragm in vertical position
Weight	8.0 oz (230 g)
Agency Approvals	CE

• Building pressure monitoring
• Duct pressure monitoring
• Fan velocity measurement
• Zone differentiral pressure monitoring
• Filter condition monitoring
