MSI-8000HD Indicator/Remote Display

MSI-8000HD Indicator/Remote Display

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
MSI 8000 HD Indicator Remote Display 10717
MSI 8000 HD Indicator Remote Display c5197

 Rugged, Versatile Control

Fortified by the acclaimed reputation of its star precursor, MSI-8000HD is the heavy duty version of the reputable handheld MSI-8000 RF remote display. The milled anodized aluminum, IP68-rated, enclosure is mountable in either a direct panel mount or optional tilt stand. The full waterproof construction resists most elements making it especially appealing to the petro-chemical, energy, marine and aerospace industries. Fully compatible with all MSI ScaleCore-based crane scales and dynamometers, the MSI-8000HD provides utmost versatility for any application.

Rugged, Versatile Communication
User-definable function keys and a bold six-digit one inch display ease usability and readability. Process control, safety and other systems benefit with optional relays installed to optimize workflow and operator ease. The MSI-8000HD meters may be used as a fully functional weigh meter with the standard inclusion of a precision 24-bit A/D. Additionally, the MSI-8000HD-2 has RF capability to transmit data to a secondary MSI-8000 or non-A/D MSI-8000HD. Wi-Fi, Ethernet or serial option cards are available for direct connections to networks and computers for advanced traceability and reporting.

• Compatible with all ScaleCore™-based products including: MSI-7300 Dyna-Link 2, MSI-3460 Challenger 3, MSI-4260 Port-A-Weigh, MSI-7000 and MSI-7001 TranSend™, MSI-9600HT and MSI-6360
• LCD display
• IP68 milled aluminum enclosure
• Time and date
• Membrane keypad for remote-control functionality
• User-definable function keys for added versatility
• Swivel tilt stand

Options
(Contact MSI for application consultation)

• Up to 8 configurable relay outputs
• Wi-Fi communications
• 802.15.4 Serial RF
• FHSS
• Wired Ethernet
Power90-267 VAC, 9-36 VDC, 18-72 VDC, 120-300 VDC
Optional battery power module available
Excitation Voltage4.8V current limited and over-voltage protected
RF Remote ChannelsUp to four remote sensors, monitored individually, in pairs or sum all (non-A/D version only)
Service CountersA/D version only
A/D InputsTwo independent or summing load cell inputs
FilteringOff, Low, Hi-1, Hi-2
RF Radio Link2.4 GHz 802.15.4
Compatible with all ScaleCore™ based products including:
MSI-7300 Dyna-Link 2, MSI-3460 Challenger 3,
MSI-4260 Port-A-Weigh, MSI-7000 and MSI-7001
RF Effective RangeTypically 100 to 300 ft, line of sight; for longer range consult factory
Communication PortsDual RS-232 communication ports
Optional CommunicationsWi-Fi
Serial RF (Single Sequence or FHSS)
AnnuciatorsStable, COZ, peak, kg, kN. lb, M, ton, setpoint, function LEDs
Channels: 1, 2, 3, 4, TTL
DisplaySix-digit 1.0 in (26.4 mm) LCD
Units DisplayedPounds, kilograms, tons, metric tons, kilonewtons
Keys/ButtonsOn/Off, Zero (100%), Tare, Print, and Two user-defined keys for the following functions: peak hold, high resolution, total, view total, net/gross, units switching
Rating/MaterialEnclosure: NEMA Type 4, IP68 milled anodized aluminum with O-ring gaskets
Temperature RangeOperating: -4 °F to 140 °F (-20 °C to 60 °C)
Certified: 14 °F to 104 °F (-10º °C to 40 °C)
WarrantyOne-year limited
ApprovalsNTEP CC 15-110 (-10 °C to 40 °C)
