OctTempV2 / OctTemp2000 8 Channel Thermocouple Data Logger
Eight channel thermocouple data logger with a reading rate of up to 4 Hz, can measure and record data for up to 500,000 readings per channel
This product is no longer available. Contact us at 800-567-8686 for alternative solutions.
The OctTemp is an eight channel thermocouple data logger with a reading rate of up to 4 Hz. It can measure and record 500,000 readings per channel. To maximize memory capacity, users can enable or disable channels. For easy identification, each channel can be named with up to a ten digit title.
In addition, the OctTemp features individual cold junction compensation for each channel providing increased accuracy and response time, and if a probe is removed or severed during logging, the software automatically annotates the data. The device accepts J, K, T, E, R, S, B and N type thermocouples.
The OctTemp is ideal for a variety of applications, whether it is remote temperature monitoring, or multiple points in a central location. Data from all channels is simultaneously logged. After the monitoring cycle is complete, data can be downloaded to a PC for analysis.
The OctTemp is also available with an LCD screen (OctTemp2000). It features onscreen minimum, maximum and average statistics, as well as a user configurable graphics screen that allows for any combination of channels to be displayed.
Thermocouple plugs and probes sold separately.
• 4 Hz reading rate
• 500,000 readings per channel
• Open channel detection
• Title channels
• Accepts thermocouple types J, K, T, E, R, S, B, N
• External power or user replaceable battery
• Pushbutton or programmable start
• Monitor multiple points
• Warehouse monitoring
• Refrigerator monitoring
• Medical and pharmaceutical
• Oven monitoring
• Smoke houses
• Food processing
• HVAC
• Engine studies
