OMEGA

OS-880-121 -30 to 550°C, 12:1 Essential Infrared Thermometer

-30 to 550°C, 12:1 FOV, Infrared Thermometer

Normally ships in
3-4 weeks
Have questions? We're here to help!
Have questions? We're here to help!

Supported Applications

The Omega OS880 Series is an essential handheld infrared thermometer designed for non-contact surface temperature sensing. The device measures hot, hazardous, or hard-to-reach objects without physical contact.

Operating Conditions & Performance

The series operates within a measurement range of -30 to 550°C (-22 to 1022°F), with the spec sheet noting an extended capability down to -50°C. Accuracy is specified as ±3°C or ±3% of rdg for temperatures from -30°C to 0°C (-22 to 32°F); ±2°C or ±2% of rdg for 0°C to 100°C (32 to 212°F); and ±3°C or ±3% of rdg for ≥100°C (212°F). The instrument features a display resolution of 0.1°C or 0.1°F, a response time of 500 ms (95% response), and a field of view ratio of 12:1.

Performance is supported by an adjustable emissivity setting from 0.1 to 1.0 and a spectral response range of 8 – 14 µm. The unit operates in ambient temperatures between 0 - 40°C (32 - 104°F) with relative humidity up to 95% RH, though the manual specifies an operating humidity range of 10 - 95% RH.

Configuration Options

The OS880 Series is offered as a single model configuration: OS-880-121. Key configurable and functional features include:

• Sensor & Display: Backlit display automatically illuminated when the trigger is pulled; reading updates continuously while triggered and holds on release.
• Aiming System: Single laser for aiming, activated automatically with the trigger.
• Data Functions: Adjustable emissivity (0.1 to 1.0), minimum value, maximum value, averaging functions, and high/low alarm capability.
• Power & Dimensions: Powered by a 9V alkaline battery with an estimated life of 12 hours typical using the laser; overall dimensions are 5.74 x 3.14 x 1.49 in (146 x 80 x 38 mm) and weight is 130 g (4.5 oz to 4.58 oz without battery).
• Storage: Storage temperature range of -20 - 60°C (-4 - 140°F).

Key Product Differences

The series is represented by the OS-880-121 model, described as an essential handheld infrared thermometer with a 12:1 field of view and a measurement range extending to -50°C in specification tables. The device includes CE certification per manual documentation.

  • -50 to 550°C (-58 to 1022°F) temperature range
  • 12:1 Field of View
  • Adjustable Emissivity: 0.10 to 1.00
  • 500 ms response time



Accuracy± 2 °C (± 3.6 °F)
Accuracy Detail± 3°C or ± 3% of rdg, -30°C to 0°C (-22 to 32°F) ± 2℃ or ± 2% of rdg, 0℃ to 100℃ (32 to 212°F) ± 3°C or ± 3% of rdg, ≥100℃ (212°F)
Additional Features 1"Hold" function retains the last reading
AlarmHigh and Low
Battery life12 hr
Battery Size and TypeAlkaline 9V
Display TypeLCD
Emissivity, Max1
Emissivity, Min0.1
Emissivity NoteAdjustable 0.10 to 1.00
Field of view12:1
Form factorPistol Grip
Height146 mm
LaserSingle Laser
Length39 mm
Operating Temperature, Max40 °C
Operating Temperature, Min0 °C
Process Temperature, Min-50 °C
Resolution0.1°C
Response Time500 ms
Response Time Note500 ms (95% response)
Series IDOS880-Series
Spectral Response, Max14 µm
Weight130 g
Weight Note130g (4.5 oz) without battery
Width80 mm
  • Download

    Data Sheet - OS-880-121 -30 to 550°C, 12:1 Essential Infrared Thermometer

    Download
  • Download

    Manual - OS-880-121 -30 to 550°C, 12:1 Essential Infrared Thermometer

    Download
