OS530LE Handheld IR Thermometer -23°C to 871°C Temperature
OMEGASCOPE™ Handheld Infrared Thermometer Enhanced E Versions - Now Available!
This product is no longer available. Contact us at 800-567-8686 for alternative solutions.
With a combination of powerful features, the portable and rugged OS530E series infrared thermometers offer solutions for many non-contact temperature measurement applications. Emissivity adjustable from 1.00 to 0.10 in 0.01 increments, the OS530E series provides versatility when measuring a variety of surfaces.
A custom backlit LCD display provides dual digital display of both current and max, min, diff or average temperatures simultaneously. This provides the user with more information at a glance. Built-in laser sighting creates a 12-point circle which clearly indicates the target area being measured.
The OS530E Series also features a high alarm setpoint, providing both audible and visual indication of the alarm status. The standard 1 mV per degree analog output allows interfacing with data acquisition equipment, including chart recorders, data loggers and computers.
All Models Feature: Adjustable Emissivity, Backlit Dual Display, Differential Temperature, Min/Max Temperature, Average Temperature, High Alarm, Audible Buzzer & Indicator, Analog Output (1mV/Deg), Laser Sight (Built-In), Trigger Lock, Last Temperature Recall. OS532E Adds Thermocouple Input, OS533E Adds Low Alarm, Ambient Target Temperature Compensation, RS-232 Output, Thermocouple Input. OS534E Adds all of the OS533E Features plus Data Storage.
Caution: This product and all in the series are not for use in medical evaluations. These products cannot be used to measure body temperature. They are meant for industrial and scientific purposes.
• Rugged, High-Performance Design
• Built-In Laser Sighting is Switchable Between Laser Dot and Circle Patterns
• The Laser Can be Flashing or Continuous
• Includes High-Performance, General Purpose, Close-Focus, and HighResolution Models
• Models Available with Temperature Ranges from -23 to 871°C (-10 to 1600°F)
• Emissivity Adjustable from 0.1 to 1.00 in 0.01 Steps
• Models OS532E, OS533E, OS534E Come with 6" Long Type K Surface Probe
• Backlit LCD
• Dual Digital Display Indicates Current Temperature as well as Min, Max, Average, or Differential Temperatures 3
• °C/°F Switchable
• 1 mV/Degree Analog Output Standard
• RS232 Output Models Include FREE Windows® Based Data Logging Software
• Audible and Visible Alarms
• Integral Tripod Mount
• Type K Thermocouple Input Available
• Temperature Data Storage Available on OS534E (up to 800 Data Points)
• Electronic Trigger Lock
• Last Temperature Recall
• All Models Include Built-In Laser Sighting, Display and Lens Protective Bumpers, Wrist Strap, Soft Carrying Case, 4 “AA” Lithium Batteries, Portable Mini-Tripod and User’s Manual with Emissivity Reference Chart
