Precision Digital

PD6900-GP VantageView+ NEMA 4X Loop-Powered Process/Ft & In Level Indicators

Installed in a variety of harsh operating environments to provide convenient and informative display of any 4-20 mA signal

Starting at
$808.50CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
PD6900 GP Vantage View NEMA 4 X Loop Powered Process Ft In Level Indicators 07952

The VantageView+ loop-powered meters can be installed in a variety of harsh operating environments to provide convenient and informative display of any 4-20 mA signal. One of the most convenient features is the dual-line display, typically used to display the process variable on the 5-character alphanumeric top display and the units of measure or tag on the 8-character alphanumeric bottom display. Feet and inches models display level in feet and inches on the top display while the 8-digit alphanumeric bottom line may be used to display a tag or custom message. Further enhancing the display on these instruments is a 20-segment bargraph.


Four CapTouch through-glass buttons are available to operate the instrument without removing the cover. The CapTouch buttons have two modes of operation: Normal and Delayed, and they can be disabled for security via a switch on the display module.

All models come equipped with two open collector outputs and a digital input. There are also models available with two solid-state relays and isolated 4-20 mA analog output options. The open collector outputs are useful for alarm indication. The digital input can be used to acknowledge the relays, to start/stop a timer/stopwatch, and more. The relays can be programmed for alarm indication, on/off control, or pump alternation.

Free, PC-based, MeterView XL software that connects to the meter via a micro USB cable is available for programming and setup of the meters. This software greatly simplifies the programming process and also allows the user to save configuration files for later use. The meter will also be powered by the USB connection so no additional power is needed during programming.

 • Loop-Powered Field-Mount Meters

• 4-20 mA Input Displayed with ±0.02% of Full-Scale Accuracy
• 1.5 Volt Drop (4.7 Volt Drop with Backlight)
• 0.7" (17.0 mm) 5 Digits 7-Segment, FT-IN & Fractions Top Display (PD6907)
• 0.7" (17.0 mm) 5 Alphanumeric Characters Top Display (PD6908)
• 0.4" (10.2 mm) 8 Alphanumeric Characters Bottom Display
• Displays Level in Feet & Inches up to 999 Feet, 11 & 15/16 Inches (PD6907)
• 20-Segment Bargraph Standard
• CapTouch Through-Window Button Programming with Normal and Delayed Modes
• Loop-Powered Backlight with Red Backlight for Alarm Conditions
• (2) Open Collector Outputs Standard; Assignable to Pulse, Alarm, Timer, or Stopwatch
• (2) Optional Loop-Powered Solid-State Relays; Assignable to Alarm, Control, Timer, or Stopwatch
• Stopwatch & Timer Functions to Drive Relays & Open Collectors
• Optional Isolated 4-20 mA Analog Output
• Relay Pump Alternation Based on Level and Runtime
• Round Horizontal Tank Function; Just Enter Diameter & Length
• 32-Point Linearization, Square Root Extraction and Programmable Exponent Function
• Free PC-Based MeterView XL USB Programming Software
• Operating Temperature Range: -40 to 75°C (-40 to 167°F)
• Conformal Coated PCBs for Dust & Humidity Protection
• Plastic NEMA 4X, IP66 Enclosure
• 3-Year Warranty
