Precision Digital

PD6938-GP VantageView+ NEMA 4X Pulse Input Flow Rate/Totalizer

Installed in a variety of areas to provide convenient and informative display of flow rate and total from any pulse output flowmeter

Starting at
$1,003.50CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
PD6938 GP Vantage View NEMA 4 X Pulse Input Flow Rate Totalizer 08589

 The PD6938 VantageView+ pulse input flow rate/totalizers can be installed in a variety of areas (dirty, wet, corrosive, hot, or cold) to provide convenient and informative display of flow rate and total from any pulse output flowmeter. These instruments will accept a variety of pulse inputs, including slow pulse rates. They can be powered from a battery, 9-30 VDC, or the 4-20 mA output loop, have on-board datalogging capabilities, and can be ordered with optional 4-20 mA output and two relays.


The PD6938, with the addition of its two optional relays, can also be used as a simple batch controller.

One of the most convenient features of these instruments is their dual-line display, which is typically used to display the flow rate on the top display and flow total, flow grand total, or a tag on the bottom display. The top display has five characters and the bottom display has eight characters for clear indication of tags, units, or alarm messages. Further enhancing the display on these instruments is a 20-segment bargraph and backlighting that can turn red during an alarm condition.

The PD6938 VantageView+ comes in a NEMA 4X, IP66 plastic enclosure that is designed for easy use and installation. There are three 3/4" NPT threaded conduit holes available for wiring. Two 3/4" NPT plastic conduit plugs are included. Field wiring is made to removable screw terminals and the display module can be oriented in 4 different positions to accommodate different mounting configurations and requires no tools to install. The display has been designed to optimize viewing angle.

Free, PC-based, MeterView XL software that connects to the meter via a micro-USB cable is available for programming and setup of the instruments. Four CapTouch through-window buttons are available to operate the instrument without removing the cover.

All models come equipped with two open collector outputs and a digital input. There are also models available with Modbus RTU RS-485 communications, two solid-state relays, and isolated 4-20 mA analog output options. The open collector outputs are useful for alarm indication or pulse output. The digital input can be used to reset the total, to start/stop a timer/stopwatch, to start/stop a batch, and more. The relays can be programmed for alarm indication, on/off control, or simple batch control.
• Field-Mount Pulse Input Flow Rate/Totalizers
• NPN Open Collector, PNP, TTL, Switch Contact, Sine Wave (Magnetic Pickup Coil), or Active Square Wave Inputs
• Top Display: Five 12-Segment Alphanumeric Characters, 0.7" (17.8 mm)
• Bottom Display: Eight 14-Segment Alphanumeric Characters, 0.4" (10.2 mm)
• Display Mountable at 0°, 90°, 180°, & 270° (No Tools Required)
• CapTouch Through-Window Button Programming with Normal and Delayed Modes
• Red Backlight for Alarm Conditions, Enable and Disable Backlight from Menu
• 8-Digit Total & Grand Total Display, Up to 13 Digits Using Both Lines
• Display Rate & Total Simultaneously
• Bi-Directional Flow Detection Via Digital Input
• Non-Resettable Grand Total
• Display Previous Total and Previous Grand Total with Time-of-Day Reset Feature
• Reset Total / Grand Total with CapTouch Button, Digital Input, or Time-of-Day Feature
• Automatic or Manual Batch Control
• K-Factor Calibration or Scaling with Up to 32-Point Linearization
• Gate Function for Rate Display of Slow Pulse Rates
• (2) Open Collector Outputs Standard; Assignable to Pulse, Alarm, Timer, or Stopwatch
• (2) Optional Solid-State Relays; Assignable to Alarm, Sample, Timer, Batch Control, or Stopwatch
• Optional Isolated 4-20 mA Analog Output
• Free PC-Based MeterView XL USB Programming Software
• 9-30 VDC or 4-20 mA Output Power Options
• Modbus RTU RS-485 Communications Standard on DC & Battery Powered Models
• On-Board Data Logging of up to 2,032 Records and Modbus Accessible Data
• Password Protection for Settings, Total & Grand Total
• Operating Temp Range: -40 to 75°C (-40 to 167°F)
• Conformal Coated PCBs for Dust & Humidity Protection
• Flange for Wall or Pipe Mounting; Loop for Stainless Steel Tag; Holes for Tamper-Proof Seal
• Plastic NEMA 4X, IP66 Enclosure with Three 3/4" NPT Threaded Conduit Openings
• 3-Year Warranty
