Precision Digital

PD8-150 ProtEX-MAX Explosion-Proof Alarm Annunciator

Offers all the functionality of the Vigilante II PD150 as a fully FM, CSA, ATEX, & IECEx approved explosion-proof product

Starting at
$2,262.00CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
PD8 150 Prot EX MAX Explosion Proof Alarm Annunciator 00762
PD8 158 Left

The ProtEX-MAX PD8-150 offers all the functionality of the Vigilante II PD150 as a fully FM, CSA, ATEX, and IECEx approved explosion-proof product. It provides alarming and monitoring capabilities for all of your level, pressure, flow, and other process switches. These explosion-proof alarm annunciators are available in two models; the PD8-154 has four (4) inputs and the PD8-158 has eight (8) inputs. Each model accepts inputs from relays, float switches, digital outputs, and many other discrete (on/off) devices. They can be field programmed for all common ISA alarm sequences including first out indication and provide alarm signaling through front panel LEDs and a built in 85 dB horn. The silence, acknowledge, and reset functions can be operated without opening the housing by using the built-in SafeTouch® through-glass buttons. Custom printed message labels can be included with your order at no additional charge.



• 8 field selectable sequences
• 4 or 8-point monitoring
• All common ISA sequences
• Multiple-unit first-out indication
• 2 SPDT relays for alarm activated devices
• Silence, acknowledge, and reset functions
• SafeTouch® through-glass button programming
• Flanges for wall or pipe mounting

Alarm MessagesCustom printed adhesive clear labels.
AreaPD154, 1.25" x .60" (32 mm x 15 mm), 4 messages PD158, 1.25" x .25" (32 mm x 6 mm), 8 messages
User specified size and length, up to 4 lines (PD154) or 2 lines (PD158) of 14 characters of size 9 pt fonts.
Programming MethodsRear 4-position switch for sequence selection and horn operation. Three SafeTouch through-glass buttons for NO/NC input selection, sequence option, and operation when cover is installed. Three internal pushbuttons when cover is removed.
Audible Alarm85 dB internal horn. The use of an external explosion-proof horn is recommended due to the internal horn's audibility being dampened by the explosion-proof enclosure.
Noise Filter40 ms debounce on inputs and external push buttons.
Shared First-Out Systems1 ms unit-to-unit delay. Maximum of 200 units in the shared first-out system.
Non-Volatile MemoryAll programmed settings are stored in non-volatile memory for a minimum of ten years if power is lost.
Power Options85-265 VAC, 50/60 Hz; 90-265 VDC, 20 W max; or 12-36 VDC, 12-24 VAC, 6 W max.
FuseRequired external fuse: UL Recognized, 5 A max, slow blow. Up to 6 annunciators may share one 5 A fuse
Isolated Power Supply24 VDC ± 10% @ 200 mA max Standard on 85-265 VAC powered units only.
Isolation4 kV input/output-to-power line.
Overvoltage CategoryInstallation Overvoltage Category II: Local level with smaller transient overvoltages than Installation Overvoltage Category III.
EnvironmentalT6 Class operating temperature range Ta = -40 to 60°C
T5 Class operating temperature range Ta = -40 to 65°C
ConnectionsRemovable screw terminal blocks accept 12 to 22 AWG wire.
EnclosureExplosion-proof die cast aluminum with glass window, corrosion resistant epoxy coating, color: blue. NEMA 4X, 7, & 9, IP68. Default conduit connections: Four ¾" NPT threaded conduit openings and two ¾" NPT metal conduit plugs with 12 mm hex key fitting installed. Additional conduit opening configurations may be available; verify quantity and sizes on specific device labeling during installation.
MountingFour slotted flanges for wall mounting or NPS 1½" to 2½" or DN 40 to 65 mm pipe mounting.
DisplayPD8-154: Four red LED channel indicators. PD8-158: Eight red LED channel indicators. One green LED power indicator.
Overall Dimensions (W x H x D)6.42" x 7.97" x 8.47" (163 mm x 202 mm x 215 mm)
Weight16.0 lbs (7.26 kg)
Warranty3 years parts & labor
