Buy now! $128.11CAD
Fluke

Pocket Toner

Connects to any voice, data, or video cable to detect open/short circuits, continuity, AC/DC voltage* & dial tone* all while protecting up to 52 volts

Buy now!
$128.11CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
Pocket Toner 11681
Pocket Toner 5b54a
Pocket Toner 60eeb
Pocket Toner 68246
Pocket Toner 747da
Pocket Toner 830a6
Pocket Toner b0ef0
Pocket Toner c06ca
Pocket Toner e8583

 The Pocket Toner® connects to any voice, data, or video cable to detect open/short circuits, continuity, AC/DC voltage* and dial tone* all while protecting up to 52 volts.


The Pocket Toner comes in three models and several different kit configurations so no matter what your job, you can safely install and test.

All of the Pocket Toners have dual audible indicators in the main body and detachable buzzer toner units, removable push on connectors, auto shut-off and easy-to-read indicators.

Pocket Toner® NX1 – Identify and test live, singular coax cables for continuity, opens and shorts.

Pocket Toner® NX2– All the features of the NX1 plus more—test coaxial cables for continuity, AC and DC voltage, shorts, opens, 50-75 Ω termination, and polarity with Dial Tone Detective™ adapter.

Pocket Toner® NX8 – All the features of the NX1 and NX2 plus more—test up to 8 cables at once for continuity, shorts, opens, 50-75 Ω termination, and polarity with Dial Tone Detective™ adapter.

 The Pocket Toner® connects to any voice, data, or video cable to detect open/short circuits, continuity, AC/DC voltage* and dial tone* all while protecting up to 52 volts.


The Pocket Toner comes in three models and several different kit configurations so no matter what your job, you can safely install and test.

• Low-voltage circuit protection for both the unit as well as the detachable cable toner
• Dual audible indicators in the main body and detachable buzzer toner units
• Removable push on connectors
• Auto shut-off
• Easy-to-read indicators
• Male and female adaptable toner section
• Removable push-on connector
• Lightweight, durable anodized aluminum body
Approximate DistanceRG6: 300 m (1,000 ft)
Output voltage in continuity mode3.6 Vdc (with a new battery)
Toner frequencyMain unit: 2.7 kHz. Toner cap: 2.3 kHz
Maximum input voltage60 Vdc
Battery type1.5 V AAA alkaline
Auto shut-off10 minutes
Operating temperature-20 °C to +65 °C
Storage temperature-30 °C to +70 °C
Altitude3,000 m (10,000 ft) maximum
Relative humidity5 % to 95 % (non-condensing)
Dimensions and weight5.4 in x 0.6 in (138 mm x 15 mm), 2.2 oz (62.4 g)
Listed by the Canadian Standards Association CSA C22.2 No. 61010.1.04
