PX605-100GI General Purpose Pres. Transducers w/Adjustable Zero & Span

0 to 100 psi, Gauge, 4 to 20 mA, 1/4" NPT Male, Cable

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
PX605 100 GI General Purpose Pres Transducers w Adjustable Zero Span 14147
• Excellent Long Term Stability
• All Stainless Steel Construction
• NEMA 4 Cable or Connector Models
• 0.4% Accuracy
Excitation10 to 36 Vdc unregulated
OutputPX603/PX613 Series: 1 to 5 Vdc (3 wire)
PX605/PX615 Series: 4 to 20 mA (2 wire)
Supply Current<3.0 mA
Insulation Resistance100 MΩ @ 50 V
Accuracy±0.4% BFSL (Includes non-linearity, hysteresis and non-repeatability errors) ±1.0% Terminal Point Method Includes non-linearity, hysteresis, non-repeatability, zero offset and span setting errors
Hysteresis±0.2% FS
Repeatabiltiy±0.07% FS
Stability±1.0%/year
Durability100 million cycles
Operating Temperature-28 to 82°C (-20 to 180°F)
Compensated Temperature-28 to 71°C (-20 to 160°F)
Thermal Zero Effect±0.04% FS/°F
Thermal Span Effect±0.04% FS/°F
Proof Pressure
15 to 2000 psi= 200% FS
7500 to 20,000 psi= 120% FS
Burst Pressure
15 to 2000 psi= 800% FS
3000 to 5000 psi= 300% FS
7500 to 20.000 psi= 150% FS
GagesThin-film polysilicone
Diaphragm17-4 PH stainless steel
Case300 Series stainless steel
Pressure Connection
15 to 10,000 psi= ¼ NPT
>10,000 psi= female Aminco fitting (9/16-18 UNF)
Electrical Connection0.9 m (36') braided-shield PVC cable or connector
Mating ConnectorPT06F8-4S (not included)
Weight128 g (4.5 oz) without cable
Response Time5 ms
ConstructionSealed units, except PX603 and PX605 ≤500 psi is vented to room
3000 to 5000 psi= 150% FS
