RFC1000-IP69K Splashproof Transceiver

Name: RFC1000-IP69K Splashproof Transceiver
Brand: Madgetech
SKU: placeholder-rfc1000-ip69k-splashproof-transceiver
Price: 448.50 CAD
Availability: InStock

Splash proof wireless transceiver for the RFOT, Therm-A-Lert and RF2000A series of data loggers

Buy now!

$448.50CAD

Have questions? We're here to help!

Call

QTY

Used in

RFC1000 IP69 K Splashproof Transceiver 01877

Splash proof wireless transceiver for the RFOT and RF2000A series. Includes USB to mini USB adapter and RFC1000-IP69K wireless transceiver. The splash proof transceiver can be installed directly in the wash down location, ensuring 100% communication throughout the entire process. This model includes a high powered transceiver with an IP69K ingress protection rating.

The RFC1000-IP69K has a substantial transmit range, providing superior performance in occluded environments such as ovens and refrigerators. The RFC1000-IP69K also includes an external antenna which is protected by a neoprene boot, allowing more flexibility with mounting positions in both orientation and proximity to metal walls. The RFC1000-IP69K is designed to communicate between MadgeTech’s two-way wireless data loggers and the MadgeTech software. Connects to a maximum of 64 data loggers.

• Functions as both a repeater and a transceiver
• Green and red LED indicators
• Compatible with MadgeTech’s RFOT, Therm-A-lert and RF2000A series of data loggers

Frequency	2.405 GHz - 2.475 GHz
Operating Environment	Enclosure: -20 °C to 80 °C (-4 °F to +176 °F) Power Supply: 0 °C to 45 °C (32 °F to +113 °F)
Dimensions	Enclosure 3.4 in x 2.9 in x 1.3 in With antenna, normal to case: 3.4 in x 2.9 in x 8.8 in With antenna, laid down: 9.2 in x 2.9 in x 2.6 in
Weight	14.1 oz (400 g)
Materials	• Enclosure Body: Acetal Plastic • Cover: 300 Series Stainless Steel • Antenna Boot: Neoprene
Compatible Data Loggers	RFOT and RF2000A Series
Transmission Distance (to data loggers)	Unobstructed line-of-sight (outdoors): 2,000 ft max. Typical urban environment (indoors): 500 ft max.
Transmission Distance (to other RFC1000-IP69K's)	Unobstructed line-of-sight (outdoors): 2,500 ft max. Typical urban environment (indoors): 700 ft max.

General
Materials	Enclosure Body	Acetal Plastic
	Cover	300 Series Stainless Steel
	Antenna Boot	Neoprene
Compatible Data Loggers	RFOT, Therm-A-lert, RF2000A Series
Outdoor Line of Sight	To Repeaters	4000 ft
	To Loggers	2000 ft
Indoor Line of Sight	To Repeaters	1000 ft
	To Loggers	500 ft
Frequency	2.405 GHz - 2.475 GHz
Operating Environment	Enclosure	-20°C - 80°C (-4°F - 176°F)

• General wireless data logging
• Meat cooking and cooling
• Meat storage
• Smoke houses
• Food processing
• Medical storage
• Laboratory monitoring
• Blood banks
• Hospitals
• Warehouses
