RHTemp101A Humidity and Temperature Data Logger

Name: RHTemp101A Humidity and Temperature Data Logger
Brand: Madgetech
SKU: placeholder-rhtemp101a-humidity-and-temperature-data-logger
Price: 238.50 CAD
Availability: InStock

State-of-the-art humidity & temperature data logger used for warehouse, museum monitoring, & HVAC studies

Buy now!

$238.50CAD

Have questions? We're here to help!

Call

QTY

Used in

RH Temp101 A Humidity and Temperature Data Logger 01801

The RHTemp101A is a compact, humidity and ambient temperature data logger. This device can measure and record temperatures from -40 °C to 80 °C (-40 °F to +176 °F) and humidity from 0 %RH to 95 %RH.

The RHTemp101A features user-specified high/low alarm limits and can even be programmed to start up to 18 months in advance. With a 10-year battery life and the ability to store up to 1,047,552 time and date stamped readings, the RHTemp101A is perfect for long-term studies.

The RHTemp101A is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

10 Year Battery Life
1 Second Reading Rate
Multiple Start/Stop function
Ultra High Speed Download
1,047,552 Readings Per Channel, Storage Capacity
Memory Wrap
Battery Life Indicator
Optional Password Protection
Programmable High and Low Alarms
NIST Traceable
Field Upgradeable

General
Memory	1,047,552 readings
Reading Rate	1 reading every second up to 1 reading every 24 hours
Alarm	Yes, Humidity
Baud Rate	115,200
LED Indicators	Red & Green
Push-Button Start	Yes
Battery Life	10 years typical at a 15 minute reading rate
Material	Polycarbonate
Dimensions	1.4 in x 2.1 in x 0.6 in (35 mm x 54 mm x 15 mm)
Operating Environment	-40 °C to +80 °C (-40 °F to +176 °F), 0 %RH to 95 %RH non-condensing
Required Interface Package	IFC200
Approvals	CE
Temperature
Temperature Sensor	Precision RTD Element
Temperature Range	-40 °C to +80 °C (-40 °F to +176 °F)
Temperature Resolution	0.01 °C (0.018 °F)
Temperature Calibrated Accuracy	±0.5 °C (±0.9 °F) from 0 °C to 55 °C (+32 °F to +131 °F) ±1.0 °C (±1.8 °F) from -40 °C to 0 °C (-40 °F to +32 °F) and +55.01 °C to +80 °C (+131.01 °F to +176 °F)
Humidity
Humidity Sensor	Internal semiconductor
Humidity Range	0 %RH to 95 %RH
Humidity Resolution	0.1 %RH
Humidity Calibrated Accuracy	±3.0 %RH
Humidity Accuracy Range	25 % RH to 75 % RH, 20 °C to 40 °C, Hysteresis Error 1 % Typ 3 % Max
RH Units	%RH, dew pt., water vapor, concentration (mg/hl)
