RL1040 Aluminum Single Point Load Cell

Rice Lake RL1040 Aluminum, Single Point Load Cell

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
RL1040 Aluminum Single Point Load Cell 10882

 The RL1040 maintains long-term stability and durability. Potted cavities provide improved performance in damp environments. NTEP Certified capacities range from 5 kg to 100 kg. Complete with 10 ft of load cell cable.

ApprovalscFMus
NTEP 95-074
WarrantyTwo-year limited
Max Platform Size15.75 × 15.75 in
Cable Color CodeGreen +Excitation
Black –Excitation
Red +Signal
White –Signal
Blue +Sense
Brown –Sense
Cable Diameter0.200 in PVC jacket
Cable Length10 ft
Deflection at Capactiy0.4 mm
Insulation Resistance2,000 megohm
Combined Error0.02% full scale
Rated Excitation5 to 10 VDC (15 V maximum)
Safe Overload200% at center loading point, full scale
Seal TypePotted, IP67
Unpotted, IP65
TemperatureCompensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Material/FinishAnodized aluminum
Input Resistance415 (± 5) ohm
Output Resistance350 (± 3) ohm
Full Scale Output2.0 mV/V
