RL2000SS Stainless Steel, S-Beam Load Cell

Rice Lake RL20000SS Stainless Steel, S-Beam Load Cell

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
RL2000 SS Stainless Steel S Beam Load Cell 10823

 For suspended applications or mechanical scale conversions, this model provides the additional protection of stainless steel necessary in dry, corrosive environments. Available in capacities ranging from 50 lb to 20,000 lb.

ApprovalsNTEP CC 98-078
cFMus Approved
WarrantyTwo-year limited
Cable Color CodeRed +Excitation
Black -Excitation
Green +Signal
White -Signal
Cable Length20 ft
Insulation Resistance5,000 megohm
Combined Error0.03% full scale
Rated Excitation5 to 10 VDC (15 V maximum)
Safe Overload150% full scale
Seal TypeEnvironmentally sealed, IP67
TemperatureCompensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Material/FinishStainless steel
Input Resistance390 (± 15) ohm
Output Resistance350 (± 3.5) ohm
Full Scale Output3.0 (± 0.008) mV/V
  • Thumbnail of document Data Sheet - RL2000SS Stainless Steel, S-Beam Load Cell
    Download

    Data Sheet - RL2000SS Stainless Steel, S-Beam Load Cell

    Download
