RL39123 Stainless Steel, Single-Ended Beam Load Cell

Rice Lake RL39123 Stainless Steel, Single-Ended Beam Load Cell

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
RL39123 Stainless Steel Single Ended Beam Load Cell 10839

 Single-ended beam in stainless steel. Designed for low-profile scales and process applications. Capacities range from 250 lb to 10,000 lb. Complete with 20 ft or 30 ft of load cell cable.

Full Scale Output3.0 mV/V
Output Resistance349 to 355 ohm
Input Resistance343 to 357 ohm
Material/FinishStainless steel
TemperatureOperating range:
0 °F to 150 °F (-18 °C to 65 °C)
Seal TypeEnvironmentally sealed, IP67
Safe Overload150% full scale
Safe Sideload100% full scale
Rated Excitation5 to 10 VDC (15 V maximum)
Nonlinearity0.03% full scale
Hysteresis0.02% full scale
Insulation Resistance5,000 megohm
Deflection at Capacity250 to 1,000 lb: 0.013 in
2,000 to 3,000 lb:0.015 in
4,000 to 5,000 lb: 0.025 in
10,000 lb: 0.32 in
Cable Length20 ft
30 ft
Cable Diameter0.200 in polyurethane jacket
Cable Color CodeRed +Excitation
Black –Excitation
Green +Signal
White –Signal
WarrantyTwo-year limited
ApprovalscFMus
  • Thumbnail of document Data Sheet - RL39123 Stainless Steel, Single-Ended Beam Load Cell
