Dwyer

RSMC Stabilisense Critical Room Status Monitor

Designed for critical low differential pressure applications that require stringent pressure monitoring and alarming

Starting at
$1,403.63CAD
Have questions? We're here to help!
Have questions? We're here to help!
Configure

 The Series RSMC StabiliSENSE™ Critical Room Status Monitor is designed for critical low differential pressure applications that require stringent pressure monitoring and alarming. It can be configured to monitor positive or negative pressure in clean rooms, hospital isolation rooms, school nurses offices, laboratories, and vivariums. The RSMC is a complete system with a touchscreen graphical user interface which enables access to pressure, humidity, temperature, air change, security, door status, calibration, and alarm setup. The graphical display color changes allow a clear determination of when the parameters are operating within the acceptable range (green), caution range (yellow), or have gone outside the acceptable operating range (red). The RSMC StabiliSENSE™ critical room status monitor comes standard with BACnet MS/TP and Modbus® RTU communications.

 • Long-term stable pressure measurements

• User-configurable graphical interface
• Monitors up to 3 rooms with a single unit
• Displays up to 4 parameters including pressure, relative humidity, temperature, air change, and/or door status
• Allows for flush installation in walls with space constraints with the shallow mounting depth of 1.1" (27.5 mm)
• Full color 4.3" touchscreen LCD incorporate color status indication: green for good, yellow for warning, and red for alarm
• Easy-to-clean optional brushed stainless steel bezel
• BACnet MS/TP and Modbus® RTU communications
• Includes RSMC, junction box, factory calibration certificate, and USB-C/USB-A flashdrive
ComplianceBTL, CE.
Weight1.05 lb (0.476 kg).
Audible Alarm69.1 dB 10 cm from display.
CommunicationsModbus® RTU, BACnet MS/TP.
Display4.3" (10.9 cm) color TFT LCD, dimmable; 480 x 272 resolution.
Electrical ConnectionRemovable terminal block.
Power Consumption3.6 W @ 24 VDC.
Zero and Span AdjustmentsAdjustable via touchscreen.
Temperature Units°F and °C.
Ambient Temperatuer32 to 122°F (0 to 50°C).
OutputsOne (1) digital output (DO) rated 5 A @ 30 VDC; One (1) 4-20 mA corresponding to pressure.
InputsTwo (2) user-selectable 4-20 mA, 0-5 VDC, or 0-10 VDC; USB type C used for cloning programming; One (1) digital input for door status.
Process ConnectionBarbed, fits 1/8" and 3/16" (3 mm and 5 mm) ID rubber or vinyl tubing.
Accuracy±0.25% RSS (includes non-linearity: ±0.24% BFSL, hysteresis: ±0.05% and non-repeatability: ±0.05%), or ±0.5% RSS (includes non-linearity: ±0.49% BFSL, hysteresis: ±0.05% and non-repeatability: ±0.05%).
Pressure Limits1.5 psig.
Wetted MaterialsFront: PMMA window with IP65 rating; Back housing: Fire-proof ABS+PC UL 94 V-0.
Measurement TechnologyCapacitance cell pressure sensor.
ServiceAir
Selectable Pressure UnitsPa, kPa, cm w.c., mm w.c., and in w.c.
Power Requirements24 VAC/VDC.

 • Hospital isolation rooms

• Pharmaceutical facilities
• Dental offices
• School nurse offices
• Semiconductor manufacturing facilities
