RTDTempX Temperature Data Logger

Name: RTDTempX Temperature Data Logger
Brand: Madgetech
SKU: placeholder-rtdtempx-temperature-data-logger
Price: 1071.00 CAD
Availability: InStock

Includes 4, 8, 12, and 16-channel RTD-based temperature data loggers, -200°C to +850°C

Starting at

$1,071.00CAD

Have questions? We're here to help!

Call

Configure

Used in

RTD Temp X Temperature Data Logger 06986

The RTDTempX Series includes the RTDTempX4, RTDTempX8, RTDTempX12 and RTDTempX16 RTD-based temperature data loggers. This series accepts 2, 3 and 4-wire RTDs to measure and record temperatures from -200 ºC to +850 ºC (-328 ºF to +1562 ºF) with a calibration accuracy of ±0.04 °C (±0.072 °F), all probe dependent.

In addition to having a large memory capacity, users can enable or disable channels to further maximize memory. There’s no interface necessary, the RTDTempX Series uses standard USB-A to Micro USB cable.

The RTDTempX Series is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

• ±0.04 °C Calibrated Accuracy
• Real Time Operation
• Up to 4 Hz Reading Rate
• Pushbutton or Programmable Start Time
• Title Channels
• External Power or User Replaceable Battery
• Accepts 2, 3 and 4-wire RTD’s

General
Memory	4-channel: 698,709 readings 8-channel: 349,354 readings 12-channel: 232,903 readings 16-channel: 174,677 readings
Reading Rate	4 Hz up to 1 reading every 24 hours
Channels	4, 8, 12, 16
Battery Life	18 Months
Material	Black anodized aluminum
Dimensions	4-channel: 2.70 in x 7.25 in x 1.22 in (65.6 mm x 184.2 mm x 31.0 mm) 8-channel: 2.70 in x 7.25 in x 1.22 in(65.6 mm x 184.2 mm x 31.0 mm) 12-channel: 2.70 in x 7.25 in x 1.68 in(65.6 mm x 184.2 mm x 42.7 mm) 16-channel: 2.70 in x 7.25 in x 2.14 in(65.6 mm x 184.2 mm x 54.4 mm)
Operating Environment	-20 ºC to +60 ºC (-4 ºF to +140 ºF),0 %RH to 95 %RH non-condensing
Temperature
Temperature Sensor	External: 2,3, or 4 wire RTD
Temperature Range	18.5 Ω to 390.5 Ω -200 ºC to +850 ºC (-328 ºF to +1562 ºF) (Probe Dependent)
Temperature Resolution	0.0001 Ω0.001 °C (0.0018 °F)
Temperature Calibrated Accuracy	±0.04 °C (±0.072 °F) (Probe Dependent)

• Calibration Chamber Monitoring
• Process Verification/Validation
• Warehouse Monitoring
• Precision Temperature Monitoring
• HVAC
• Clean Rooms
• Medical/Pharmaceutical
• Museum Monitoring
• Environmental Studies
• Replace Costly Strip Chart Recorders
