Lascar

SGD 43-A 4.3” with Analogue, Digital, PWM & Serial Interfaces

4.3 in display with analog, digital, PWM and serial interfaces

Buy now!
$530.87CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
SGD 43 A 4 3 with Analogue Digital PWM Serial Interfaces 00556 xl
Panel Pilot Ace Display Solutions SGD 43 A Back
Panel Pilot Ace Display Solutions SGD 43 A Laptopshot
Panel Pilot Ace Display Solutions SGD 43 A Touchscreen

SGD 43-A is a 4.3” capacitive touch display designed for use with PanelPilotACE Design Studio, a free drag-and-drop style software package for rapid development of advanced user interfaces and panel meters.  This off the shelf display features a wealth of hardware interfaces, including four 16-bit bipolar analogue inputs (to a maximum of ±40V d.c.), eight digital input/output pins, two alarm outputs, four 8-bit PWM outputs, PID Control, multi-channel data logging and trend graphs, serial RS232 and accessories available for RS485 communication and four-channel thermistor temperature measurement.

• PID Control
• Ethernet FTP for Logged Data
• Multi-Channel Data Logging
• Trend Graphs
• Previewing and Uploading Projects

Display4.3 in TFT with 262 k colours
TouchscreenCapacitive touch screen
Resolution480 x 272 pixels
ProcessorFreescale i.MX283 (454MHz, 32bit, ARM 9)
Analog InputsFour 16-bit to +/- 40 VDC
Supply5 - 30 VDC (300 mA typical at 5 VDC)
Outside Dimensions119.3 mm x 79.8 mm x 20.0 mm (4.7 in x 3.1 in x 0.8 in)
  • Thumbnail of document Guide - SGD 43-A 4.3” with Analogue, Digital, PWM & Serial Interfaces
    Download

    Guide - SGD 43-A 4.3” with Analogue, Digital, PWM & Serial Interfaces

    Download
  • Thumbnail of document Data Sheet - SGD 43-A 4.3” with Analogue, Digital, PWM & Serial Interfaces
    Download

    Data Sheet - SGD 43-A 4.3” with Analogue, Digital, PWM & Serial Interfaces

    Download
