SP-001-0 Smart IR Sensor -70°C to 380°C Temperature

Ultra miniature Smart IR Probe

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
SP 001 0 Smart IR Sensor 70 C to 380 C Temperature 13309

 The Omega Smart IR Temperature Probe is a miniature infrared sensor that measures the surface temperature of a solid or liquid without contact. It can measure non- metal surfaces between -70 to 380°C (-94 to 716°F). It also features a built-in sensor to measure the ambient temperature of the probe itself. Materials including paper, thick plastics, rubber, food and organic materials, as well as painted metals and most dirty, rusty or oily surfaces, are measured accurately, safely and cleanly.



The Smart Probe is packaged into a rugged 12 mm OD x 67 mm long compact, stainless steel, IP67 (NEMA 6) housing - designed for heavy industrial use while taking up the least amount of space for easy installation. Standard features include: easy configuration through free SYNC configuration software, adjustable emissivity and filtering, and a wide operating temperature range of -40°C to 85°C.
• Fully Integrated Microprocessor based Smart Digital Sensor solution
• 6:1 FOV
• Measures both ambient and surface temperature
• Plug-n-Play connectivity and easy setup with free Omega Sync Software
Temperature Range-70 to +380°C (-94 to 716°F)
Accuracy @ Ambient of 0-50°C (32 to 122°F):1°C (1.8°F) or 1% of reading, whichever is greater
Accuracy Over Entire Ambient Operating Range4°C (3.6 °F) or 3% of reading, whichever is greater
Repeatability1°C (1.8°F) or 1% of reading
Emissivity0.01 to 1.00, software adjustable
Response Time30 to 1500 msec, adjustable
Spectral Response5.5 to 14 microns
Supply Power3.3 Vdc, 0.05 W max
Field of ViewSP-001 is 6:1
SP-002 is 10:1
Mechanical
ContructionStainless Steel
Thread Mounting Dimensions12 OD x 114 mm L (0.47" x 4.49")
Weight35 g (1.2 oz)
Environmental
Environmental RatingNEMA 6, IP67
Acceleration Test10 g (10 to 500Hz)
Operating Temperature-40 to 85°C (-40 to 185°F) less than 95% RH, non-condensing
General
Agency ApprovalsCE, EMC 2014/30/EU, LVD 2014/35/EU
ConfigurationConfigurable via IF-001 and Sync configuration software
SoftwareCompatible with OEG and Sync configuration software
  • Thumbnail of document Data Sheet - SP-001-0 Smart IR Sensor -70°C to 380°C Temperature
    Download

    Data Sheet - SP-001-0 Smart IR Sensor -70°C to 380°C Temperature

    Download
