The State101A is a compact, state data logger that monitors and records the occurrence, duration, and status of predetermined events by measuring changes in voltage.

With a user-programmable reading rate of up to 4 Hz, 10-year battery life and the ability to store up to 838,041 readings, the State101A is ideal for long-term studies. Typically connected to a relay or switch, this device features a removable screw terminal block to easily disconnect and retrieve the logger for data download without disrupting wiring connectivity.

The State101A is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

• 10 year battery life
• 4 Hz reading rate
• Multiple start/stop function
• Ultra high speed download
• 406,323 reading storage capacity
• Memory wrap
• Battery life indicator
• Optional password protection
• Field upgradeable

Material	ABS Plastic
Dimensions	1.4 in x 2.2 in x 0.6 in (36 mm x 56 mm x 16 mm)
Operating Environment	-40 °C to +80 °C (-40 °F to +176 °F), 0 %RH to 95 %RH non-condensing
Required Interface Package	IFC200
Approvals	CE
State Input Range	0 to 30 V
State Input Low	<0.4 V
State Input High	>2.8 V
State Internal Weak Pull-Up	<60 μA
State Resolution	4 Hz (reading rate selectable in software)
Memory	406,323 readings; software configurable memory wrap
Reading Rate	4 Hz to 1 every 24 hours
Baud Rate	115,200
Channels	1
LED Indicators	Red and Green
Battery Life	10 years typical, dependent upon frequency and duty cycle

State
Input Connection	Removable screw terminal
State Input Range	0 V DC - 30 V DC
State Input Low	< 0.4 V
State Input High	> 2.8 V
State Internal Weak Pull-Up	< 60 μA
State Resolution	4 Hz (reading rate selectable in software)
Input Impedance	≥ 60 kΩ
General
Memory	500,000 readings; software configurable memory wrap 250,000 readings in multiple start/stop mode
Reading Rate	4 Hz up to 1 reading every 24 hrs
Baud Rate	115,200
Channels	1
Wrap Around	Yes
Start Modes

• Heating and cooling systems
• Security systems
• Power supply on/off
• Relay or dry contact closure
• TTL high/low
• Monitoring gas, water or electric pumps
• Status or state recording
• Replace costly strip chart recorders
