TCTemp1000 Data Logger

Rugged, submersible, battery powered, thermocouple based Temp. data logger, real time clock, records data for up to 16,383 measurements per channel

Buy now!
$508.50CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
TC Temp1000 Data Logger 01786
The TCTemp1000 is a submersible, thermocouple-based temperature data logger with stainless steel tipped 6 ft. Type K thermocouple. This device can be submerged up to 150 ft. and is adaptable to a variety of thermocouples.

The TCTemp1000 can measure and record up to 32,766 time and date stamped readings. Featuring individual cold junction compensation for each channel, the TCTemp1000 provides increased accuracy and response time.

The TCTemp1000 is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

• Rugged
• Submersible
• Real time operation
• Low cost
• Programmable start time
• Reusable
• User-friendly
• Memory wrap

Internal Channel Temperature SensorSemiconductor
Internal Channel Temperature Resolution0.1 °C (0.18 °F)
Internal Channel Temperature Calibrated Accuracy±0.5 °C
Remote Channel Temperature SensorThermocouple Types J, K, T, E, R, S, B ,N
Remote Channel Temperature RangeThermocouple Dependent
Remote Channel Temperature ResolutionThermocouple Dependent
Remote Channel Temperature Calibrated AccuracyThermocouple Dependent
Memory16,383
Reading Rate1 reading every 2 seconds up to 1 reading every 12 hours
Baud Rate2,400
Cold Junction CompensationAutomatic
Channels1 internal & 1 remote
Battery Life1 year
Material303 stainless steel
Dimensions7.4 in x 1.2 in dia (188 mm x 31 mm)
SubmersibleYes
Operating Environment-40 °C to +80 °C (-40 °F to +176 °F), 0 %RH to 100 %RH
Required Interface PackageIFC110 or IFC200

Temperature

Internal Channel

Temperature Sensor

Semiconductor

Temperature Range

-40°C - 80°C (-40°F - 176°F)

Temperature Resolution

0.1°C (0.18°F)

Calibrated Accuracy

± 0.5°C

Remote Channel

Temperature Sensor

Thermocouple Types J, K, T, E, R, S, B ,N

Thermocouple Connection

Female subminiature (SMP)

Cold Junction Compensation

Automatic, based on internal channel

Thermocouple

Type

Range

Resolution

Accuracy

J

-210°C - 760°C

0.1°C

± 0.5°C

• Extreme temperature monitoring
• Warehouse monitoring
• HVAC
• Medical and pharmaceutical
• Well monitoring
• Hostile environment monitoring
• Environmental studies
• Implement HACCP programs

  • Thumbnail of document Manual - TCTemp1000 Data Logger
    Download

    Manual - TCTemp1000 Data Logger

    Download
  • Thumbnail of document Data Sheet - TCTemp1000 Data Logger
    Download

    Data Sheet - TCTemp1000 Data Logger

    Download
