TCTemp2000 Data Logger

Name: TCTemp2000 Data Logger
Brand: Madgetech
SKU: placeholder-tctemp2000-data-logger
Price: 883.50 CAD
Availability: InStock

Thermocouple temperature data logger w/ LCD display, user replaceable battery & external power, highspeed download

Buy now!

$883.50CAD

Have questions? We're here to help!

Call

QTY

Used in

The TCTemp2000 is a thermocouple-based temperature data logger with LCD and wall mounted power adapter.

The 8-button keypad and LCD provide convenient access to current statistics (min, max, average), recording status, display options and calibration information. The TCTemp2000 can be programmed to start up to 6 months in advanced with a storage capacity of 262,143 time and date stamped readings.

The TCTemp2000 is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

• Large, backlit LCD
• Internal temperature sensor and one external input which accepts thermocouple types J, K, T, E, R, S, B, N
• Front keypad with lock feature
• High speed download
• Real-time operation
• Min./max. and average statistics
• Programmable start/stop time
• User replaceable battery and external power
• Wall mountable

Internal Channel Temperature Sensor	Semiconductor
Internal Channel Temperature Range	-20 °C to +60 °C (-4 °F to +140 °F)
Internal Channel Temperature Resolution	0.1 °C (0.18 °F)
Internal Channel Temperature Calibrated Accuracy	±0.5 °C (0 °C to +50 °C)
Remote Channel Temperature Sensor	Thermocouple Types J, K, T, E, R, S, B ,N
Memory	131,071 readings (all channels enabled)
Reading Rate	1 reading every 2 seconds to 1 reading every 24 hours
Baud Rate	262,143 readings
Cold Junction Compensation	Automatic, based on internal channel
Battery Life	1 year battery life at 1 min reading rate with display off. 30 days typical with continuous LCD and no backlight usage. Optional AC Adapter available
Material	Black anodized aluminum
Dimensions	4.8 in x 3.3 in x 1.25 in (122 mm x 84 mm x 32 mm)
Operating Environment	-20 °C to +60 °C (-4 °F to +140 °F), 0 %RH to 95 %RH non-condensing
Required Interface Package	IFC200
Approvals	CE

• HVAC applications
• Oven profiling
• HACCP program implementation
• Process verification and validation
• Warehouse monitoring
• Museum and laboratory monitoring
• Medical and pharmaceutical
• Environmental studies
• Food storage
• Live cargo transport
• Concrete curing/construction
