Dwyer

ULT - Ultrasonic Level Transmitter

Reliable, accurate, non-contact measurement of liquid levels

Starting at
$3,286.95CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
ULT Ultrasonic Level Transmitter 07439

The Series ULT Ultrasonic Level Transmitter provides non-contact measurement of liquid levels in an explosion-proof body. It is capable of measuring up to 32.8' (10 m) with a PVDF sensor and 4-20 mA output.

• Provides reliable, accurate, and non-contact level measurement of compatible liquids
• Non-contact technology offers no moving parts to wear, jam, corrode, or get coated like contact technologies
• Mapping software makes effective measuring surface only a 3" (76.2 mm) diameter column with no concerns of ladders, pipes, or other tank intrusions in the remaining sound cone
• FM approved explosion-proof making it ideal for use in hazardous locations
• Easy programming with 6 digit LCD display and simple menu structure
• Output range is adjustable with choices of inputting tank dimensions or by filling and emptying the tank while calibrating and it automatically and scaling to levels it senses
• Window cover allows easy viewing of display
• Fail-safe output options and diagnostic capabilities
Agency Approvals:CE, FM.
Weight:4.0 lb (1.8 kg).
Units:In, cm, ft, m, percent.
Display:6 character LCD.
Memory:Non-volatile.
Failsafe:On lost echo after 30 seconds, user selectable to 4, 20, 21, 22 mA or last signal.
Mounting Orientation:Vertical.
Enclosure Rating:Weatherproof meets NEMA 4X, explosion-proof rated Class I, Div. 1, Groups B, C, D; Class II/III, Div. 1, Groups E, F, G.
Process Connection:2" NPT male or optional BSPT.
Conduit Connection:1/2" NPT female (two) or optional M20.
Electrical Connections:Screw terminal.
Max. Loop Resistance:250 Ohms at 24 VDC.
Output Signal:4 to 20 mA or 20 to 4 mA (Two-wire).
Power Requirement:18 to 28 VDC (2 wire).
Pressure Limits:30 psi (2 bar) up to 25°C (77°C). Above 25°C (77°F), rating decreases 1.667 psi per 1°C increase. See Catalog page.
Temperature Compensation:-40 to 140°F (-40 to 60°C).
Temperature Limits:Ambient: -40 to 140°F (-40 to 60°C), Process: -4 to 140°F (-20 to 60°C).
Beam Width:3" (7.6 cm) diameter.
Blind Zone:Under 8" (20 cm).
Resolution:0.079" (2 mm)
Accuracy:±0.2% FS.
Ranges:24.6' (7.5 m), 32.8' (10 m).
Wetted Materials:Sensor: PVDF; Process Connection: 303 SS; O-ring: fluoroelastomer.
Service:Compatible fluids. Not for use with powder and bulk solids.
• Water and wastewater
• Pulp and paper processing
• Chemical processing
• Food and beverage
