UltraShock Temperature, Humidity, Pressure, and Tri-Axial Shock Data Logger

Name: UltraShock Temperature, Humidity, Pressure, and Tri-Axial Shock Data Logger
SKU: placeholder-ultrashock-temperature-humidity-pressure-and-tri-axial-shock-data-logger
Price: 1348.50 CAD
Availability: InStock

Stand alone, temperature, humidity, pressure, and tri-axial shock data logger with an extended battery life model available

This product is no longer sold. View active Product

Have questions? We're here to help!

Call

Ultra Shock Temperature Humidity Pressure and Tri Axial Shock Data Logger 03658

The UltraShock is a battery powered, stand alone, temperature, pressure, humidity and tri-axial shock data logger. The UltraShock measures and records data for temperature, pressure and humidity at user selectable reading rates, while shock/acceleration data is sampled at 512 Hz and at the user-specified reading rate, writes the peak acceleration (g force) to memory. An extended battery model is available (UltraShock-EB), which offers a battery life of up to 60 days typical.

The UltraShock is specifically designed for documenting dynamic environments such as moving vehicles, trucks, containers, ships, etc. The device is also valuable in characterizing environments such as production and assembly lines of delicate electronics, IC fabrication, communications and computer components.

This compact, portable, easy to use device will measure and record data for up to 174,762 measurements per channel. The storage medium is non-volatile solid state memory, providing maximum data security even if the battery becomes discharged. The device can be started and stopped directly from your computer and its small size allows it to fit almost anywhere. The UltraShock makes data retrieval quick and easy. Simply plug it into an empty USB port and our user-friendly software does the rest. The device is available in four ranges ± 5 g, ± 50 g, ± 100 g and ± 250 g.

• All inclusive design
• Built-in accelerometers
• Programmable start time
• High speed download
• Real-time operation
• Compact
• Low cost
• Reusable
• User-friendly
• CE compliant

Shock
Acceleration Range	± 5 g	± 50 g	± 100 g	± 250 g
Acceleration Resolution	0.01 g	0.05 g	0.1 g	0.2 g
Calibrated Accuracy	± 0.2 g	± 1 g	± 2 g	± 4 g
Channels	Shock (3 axes)
Accelerometer Type	MEMS Semiconductor
Absolute Max. Acceleration	250 g (all versions)
Sampling Rate	1.953 ms / 512 Hz
Accelerometer Freq. Resp.	0 Hz to approx. 400 Hz

• Complete environmental shipment monitoring
• Shipping live cargo
• Aircraft turbulence measurement
• Endurance testing
• Assembly line monitoring
• Brake & crash testing
• Laboratory drop testing
• Machinery monitoring
• Railcar coupling impacts
