VPG Celtron STC Alloy Steel, S-Beam Load Cell

VPG Celtron STC Alloy Steel, S-Beam Load Cell

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
VPG Celtron STC Alloy Steel S Beam Load Cell 10897

 Nickel plated, alloy steel construction. Suited for batching, filling and hopper/tank weighing applications. Capacities range from 250 lb to 40,000 lb. Comes with 20 ft of load cell cable.

Cable Diameter250 to 20,000 lb: 0.200 in
40,000 lb: 0.305 in
Polyurethane jacket
Cable Length20 ft
Insulation Resistance5,000 megohm
Combined Error0.02% full scale
Non-repeatability0.01% full scale
Rated Excitation5 to 10 VDC (15 V maximum)
Safe Overload150% full scale
Seal TypeEnvironmentally sealed, IP67
TemperatureCompensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Material/FinishHigh-alloy steel, nickel plated
Input Resistance385 (± 5) ohm
Output Resistance350 (± 3) ohm
Full Scale Output3.0 mV/V nominal
ApprovalscFMus
NTEP
WarrantyOne-year limited
Cable Color CodeRed +Excitation
Black –Excitation
Green +Signal
White –Signal
  • Thumbnail of document Data Sheet - VPG Celtron STC Alloy Steel, S-Beam Load Cell
