VPG Revere HPS Stainless Steel Single Point Load Cell 10986

 This stainless steel, welded-seal, low-profile single-point load cell is designed for bench scale and checkweigher applications in caustic/acidic environments. Insensitive to off-center loading and tolerates most severe washdowns. Comes complete with 10 ft of load cell cable.

Full Scale Output25 to 100 lb: 3.0 mV/V
6 kg: 2.0 mV/V
Output Resistance350 (± 7) ohm
Input Resistance400 (± 6) ohm
Material/FinishStainless steel
TemperatureOperating range
0 °F to 150 °F (-18 °C to 65 °C)
Seal TypeWelded-seal, IP67
Safe Overload150% full scale
Rated Excitation5 to 10 VAC (15 V maximum)
Combined Error0.03% full scale
Non-Repeatability0.01% full scale
Insulation Resistance5,000 megohm
Cable Length10 ft
Cable Color CodeGreen +Excitation
Black –Excitation
White +Signal
Red –Signal
WarrantyOne-year limited
ApprovalscFMus
  • Thumbnail of document Data Sheet - VPG Revere HPS Stainless Steel, Single Point Load Cell
    Download

    Data Sheet - VPG Revere HPS Stainless Steel, Single Point Load Cell

    Download
  • Thumbnail of document Manual - VPG Revere HPS Stainless Steel, Single Point Load Cell
    Download

    Manual - VPG Revere HPS Stainless Steel, Single Point Load Cell

    Download
