Dwyer

WNT Multi-Jet NSF Cert. Brass Body Water Meter

NSF Approved, Lead Free, Economical

Starting at
$251.33CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
WNT Multi Jet NSF Cert Brass Body Water Meter 09485

 The Series WNT Multi-Jet Brass Body Water Meter is a series of mechanical, water totalizing meters that display the total water usage in gallons or cubic meter. They are available in a range of body sizes and include NPT or BSPT couplings. Its lead free, NSF certified body is ideal for potable water applications.

• NSF/ANSI 61 approval makes it ideal for no lead requirements
• Multi-jet design allows for simplicity and accuracy with side flow ranges, even in low flow applications
• Magnetically driven, hermetically sealed register does not leak or fog and is completely separated from the water
• Designed for long service life and maintenance-free operation
• Integral strainer that protects meter from particulate damage
• Easy installation with included coupling adapters
• Pulsed output proportional to flow allows for remote flow totalization
Agency Approvals:NSF
WeightSee dimension chart.
Mounting OrientationHorizontal with register facing up.
Electrical ConnectionsColor-coded lead wires, 4.5' (1.5 m) long.
Electrical Rating:0.01 A @ 24 VAC/DC.
Pulse Options0.1 gal, 1 gal, 10 gal, 100 gal per pulse.
Output SignalPulse output with frequency proportional to flow rate.
Totalizing Display MaximumSee model chart.
Pressure DropSee service manual.
Pressure Limits150 psi (10 bar).
Temperature Limit122°F (50° C).
Accuracy:Transitional Flow: ±3%; Nominal Flow: ±1.5%.
Flow RangeSee model chart.
Wetted MaterialsBody: ECO BRASS®; Couplings: ECO BRASS®; Measuring Chamber: ABS Plastic.
ServiceWater
• Potable water applications
• Residential water measurement
• Remote water monitoring
