XGA301 Gas Analyzer

Standard features include two fully-programmable alarm circuits (voltage-free contacts), programmable analog outputs, RS232 communications and complete Windows-based data-logging software.

The industrial zirconia oxygen sensor provides fast and accurate oxygen analysis over the range of 1 ppm to 30%* O2 and delivers stable and repeatable readings, with a typical response time of less than 5 seconds for a 90% response to a step change in gas compositions. The zirconia sensor is heated, and temperature-controlled to enable oxygen ions to conduct. An internal pressure sensor compensates for small changes in the gas pressure to maintain accurate and stable readings. An optional, variable speed-pump draws a gas sample at a flow rate set by the user between 0 to 1.2 Nl/min.

The Easidew Sensor is available for dew points down to –100°C in combination with another sensor within the XGA301A2’s chassis.

*Analyzer is not suitable for enriched oxygen
