Madgetech

RFCurrent2000A Wireless Current Data Logger

Designed to measure and record DC current signals, available in 20 mA, 160 mA or a 3 A measurement range

Starting at
$493.50CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
RF Current2000 A Wireless Current Data Logger 01749
RF Current2000 A2
RF Current2000 A3
RF Current2000 A4
The RFCurrent2000A is a wireless DC current data logger available in three ranges: 20 mA, ±160 mA and ±3 A. The data logger can connect directly to low-level DC current sources and can also be interfaced with a wide range of current output sensors such as flow meters, pH transmitters and more.

This device features an LCD screen which provides instant access to current readings, minimum, maximum and average statistics. Equipped with user-programmable alarms, the RFCurrent2000A will alert or notify users via email or text when thresholds are breached, allowing users to take immediate action.

The RFCurrent2000A is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

The RFCurrent2000A is also MadgeTech Cloud Services ready, providing users the ability to monitor real-time data remotely on any internet enabled device, from anywhere in the world.

• Wireless data transmission
• Battery life indicator
• Digital display
• Direct USB interface
• AC Power connection via USB
• Configurable alarms
• Ability to manually reset statistics
• 4 year battery life at 15 min reading rate

Current Range20 mA: -2 mA to 30 mA
±160 mA: ±160 mA
±3 A: ±3 A
Current Resolution20 mA: 0.5 μA
±160 mA: 5 μA
±3 A: 100 μA
Current Calibrate Accuracy20 mA, 160 mA: ±0.05 %FSR
3 A: ±0.15 %FSR
Current Input Impedance20 mA: 10 Ω, ±1%
±160 mA: 1 Ω, ±1%
±3 A: <0.05 Ω
RF Carrier Frequency2.45 GHz IEEE 802.15.4 ultra-low power MadgeNET Wireless Transceiver with fully by-directional communication.
Output Power+0 dBm typical
Receiver Sensitivity -95 dBm typical
Typical Outdoors Line of SightUp to 2000 ft
Typical Indoors Line of SightUp to 500 ft
Memory32,256 readings per channel
Reading Rate1 reading every second up to 1 reading every 24 hours
Baud Rate250,000
Channels1
LED IndicatorsGreen, Blue & Red
Battery Life4 years typical at a 15 minute reading rate
MaterialABS plastic
Dimensions20 mA & 3 A: 3.19 in x 3.5 in x 0.95 in (80.9 mm x 88.9 mm x 24.1 mm) - Data logger only
160 mA: 3.17 in x 3.5 in x 0.95 in (80.5 mm x 88.9 mm x 24.1 mm) - Data logger only
IP RatingIP22
Operating Environment-20 °C to +60 °C (-4 °F to +140 °F), 0 %RH to 95 %RH non-condensing
Required Interface PackageRFC1000 (wireless); USB to Mini USB Cable
ApprovalsUS (FCC), CA (IC), CE, South Korea (KCC), China (CMIIT), Japan (LCIE)

• Battery usage studies
• Energy monitoring studies
• Photovoltaic research (PV)
• Process control instrument recording
• Data logging from sensors with current outputs (sensor not included):
    - Pressure monitoring
    - Flow rate
    - pH transmitters
