RFOT Wireless Meat Temperature Data Logger

Name: RFOT Wireless Meat Temperature Data Logger
SKU: placeholder-rfot-wireless-meat-temperature-data-logger
Price: 808.50 CAD
Availability: InStock

Wireless meat temperature data logger equipped w/ a flexible piercing probe & available in a variety of probe lengths

Starting at

$808.50CAD

Have questions? We're here to help!

Call

Configure

Used in

RFOT Wireless Meat Temperature Data Logger 01750

The RFOT is the industry standard for meat processors. This wireless meat temperature data logger provides users with real-time monitoring and is available with the following probe types:

• RFOT-FR: 1.75 in. (45 mm) fast response probe (for smaller meat products)

• RFOT-4-TD: 4.0 in. (102 mm) transitional diameter probe (for smaller meat products)

• RFOT-4: 4.0 in. (102 mm) probe

• RFOT-7: 7.0 in. (177 mm) probe

• RFOT-12: 12.0 in. (304 mm) probe

The RFOT is perfectly suited for smokehouses, ovens and other cooking processes up to 100 °C (212 °F), as well as refrigerators and freezers down to -20 °C (-4 °F). It is completely splash-resistant and can withstand wash down cycles.

The RFOT is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. The software features user-programmable critical control points, called “cooling flags” to assist in compliance with USDA Appendix B. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

The RFOT is also MadgeTech Cloud Services ready, providing users the ability to monitor real-time data remotely on any internet enabled device, from anywhere in the world.

• Wireless 2 -way communication
• Splash-proof (IP67)
• Real-time operation
• Two year battery life
• Battery life indicator
• Programmable start time
• Memory wrap around
• Field upgradeable

Remote Channel Temperature Resolution	0.01 °C (0.018 °F)
Remote Channel Temperature Calibrated Accuracy	±0.1 °C at 0 °C to +100 °C (32 °F to 212 °F) ±0.5 °C (outside of that range)
Probe Temperature Range	-50 °C to +200 °C (-58 °F to +392 °F)
RF Carrier Frequency	2.45 GHz IEEE 802.15.4 ultra-low power MadgeNET wireless transceiver with fully bi-directional communication
Output Power	+0 dBm typical
Receiver Sensitivity	-95 dBm typical
Typical Outdoors Line of Sight	Up to 2000 ft
Typical Indoors Line of Sight	Up to 500 ft
Memory	20,000 readings; software configurable memory wrap
Reading Rate	1 reading every 2 seconds to 1 every 24 hours
Baud Rate	115,200
Battery Life	2 years typical
Material	Body: Acetal Copolymer Cable Jacket: Silicone Polyurethane
Dimensions	Body: 8.66 in x 1.75 in dia. (220 mm x 44 mm dia.) Hook ID: 0.5 in (13 mm) Cable Length: 30 in (762 mm)
IP Rating	Splash proof (IP67)
Operating Environment	-20 ºC to +100 ºC (-4 ºF to 212 ºF) 0 %RH to 100 %RH non-condensing
Required Interface Package	RFC1000
Approvals	CE, US (FCC), CA (IC)

Temperature
Remote Channel Temperature Resolution	0.01°C (0.018°F)
Remote Channel Temperature Calibrated Accuracy	± 0.1°C at 0°C - 100°C (32°F - 212°F) ± 0.5°C (outside of that range)
Probe Temperature Range	-50°C - 200°C (-58°F - 392°F)
Resistance
Nominal Range	0 Ω - 500 Ω
Resolution	0.001 Ω
Calibrated Accuracy	± 0.015 Ω
Specified Accuracy Range	0 Ω - 500 Ω at 25°C
Wireless
RF Carrier Frequency	2.45 GHz IEEE 802.15.4 ultra-low power wireless transceiver with fully bi-directional communication
Band	ISM band 2.405-2.48 GHz
Maximum Output Power	+0 dBm typical
Receiver Sensitivity (RFC1000)	-95 dBm typical
