Madgetech

RFVolt2000A Wireless Data Logger

Wireless, differential voltage data logger, equipped w/ a 3 position terminal block to allow for a positive, negative & ground connection

Starting at
$493.50CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
RF Volt2000 A Wireless Data Logger 01756
RF Volt2000 A2
RF Volt2000 A3

The RFVolt2000A is a wireless data logger designed to measure and record DC voltage signals. The data logger can connect directly to DC voltage sources, making it ideal for battery usage studies, solar energy monitoring and other DC voltage monitoring applications. The RFVolt2000A can also be interfaced with a wide range of voltage output sensors, including pressure sensors and CO2 sensors, as well as transmitters and other transducers. The RFVolt2000A is available in a 2.5 V, 15 V, 30 V or 160 mV measurement range.

The RFVolt2000A-160mV model is a wireless, differential voltage data logger. The device is equipped with a three position terminal block to allow for a positive, negative and ground connection. This allows the measurement of the voltage difference between two signals tied to the same ground.

The LCD screen on the RFVolt2000A provides instant access to the current reading, as well as minimum, maximum and average statistics. Using the MadgeTech software, the device can be programmed to record in engineering units, which convert the voltage signals into a different unit of measure such as PSI, % or ppm. The statistics can be reset through the keypad of the device without erasing collected data, allowing customers to keep track of statistics over varying time periods.

The RFVolt2000A can be used as a standalone data logger, or used with the RFC1000 wireless transceiver, to transmit data back to the central PC. The RFVolt2000A can transmit up to 500 ft (line of sight) to the RFC1000 transceiver.  However, multiple RFC1000's can be set up and used as repeaters, capable of transmitting data up to 1000 ft (line of sight) to other RFC1000's. This allows the data to be sent over a greater distance.

The RFVolt2000A is compatible with the latest MadgeTech 4 Software. After downloading, the data can be viewed in graphical or tabular formats. Summary and statistic views are also available for further analysis as well as the ability to be exported to Excel®.

• Battery lfe indicator
• Digital display
• Direct USB interface
• AC power connection via USB
• Configurable alarms
• Ability to manually reset statistics
• 5 year battery life at 15 min reading rate
• 160 mV model measures differential voltage

Voltage Range2.5 V: -3 VDC to +3 VDC
15 V: -8 VDC to +24 VDC
30 V: -8 VDC to +32 VDC
160 mV:-160 mVDC to +160 mVDC
Voltage Resolution0 to 2.5 VDC: 0.1 mVDC
0 to 15 VDC: 0.5 mVDC
0 to 30 VDC: 1.0 mVDC
0 to 160 mVDC: 5 μv
Voltage Calibrated Accuracy2.5 V: ±0.05%FSR at 25 °C (77 °F)
15 V: ±0.05%FSR at 25 °C (77 °F)
30 V: ±0.05%FSR at 25 °C (77 °F)
160 mV: ±0.01%FSR at 25 °C (77 °F)
Memory32,256 Readings
Reading Rate1 reading every second up to 1 reading every 24 hours
Baud Rate250,000
LED IndicatorsGreen, Blue & Red
Battery Life5 years typical at a 15 minute reading rate
MaterialABS plastic
Dimensions3.5 in x 3.17 in x 0.95 in (88.9 mm x 80.5 mm x 24.1 mm) - Data logger only
IP RatingIP22
Operating Environment-20 °C to +60 °C (-4 °F to +140 °F), 0 %RH to 95 %RH non-condensing
Required Interface PackageRFC1000 (wireless); USB to Mini USB Cable
ApprovalsUS (FCC), CA (IC), CE, South Korea (KCC), China (CMIIT), Japan (LCIE)
Range (for each model)2.5 V: 0 to 2.5 VDC
15 V: 0 to 15 VDC
30 V: 0 to 30 VDC
160 mV: -/+160 mVDC
Accuracy (for each model)15 V: ±0.05%
160 mV: ±0.01%
Resolution (for each model) 2.5 V: 0.1 mVDC
15 V: 0.5 mVDC
30 V: 1.0 mVDC
160 mV: 5 μV

• Battery usage studies
• Solar cell monitoring
• Cathodic protection monitoring
• Pressure monitoring
• CO2 monitoring
• 160 mV model measures radio or electromagnetic frequency interference
