Starting at $5,392.50CAD

VTMS Vaccine Temperature Monitoring System Data Logger

Name: VTMS Vaccine Temperature Monitoring System Data Logger
SKU: placeholder-vtms-vaccine-temperature-monitoring-system-data-logger
Price: 5392.50 CAD
Availability: InStock

Wireless vaccine temperature monitoring system, recording temperatures as low as -100 °C

Starting at

$5,392.50CAD

Have questions? We're here to help!

Call

Configure

Used in

VTMS Vaccine Temperature Monitoring System Data Logger 01761

The VTMS Includes:

(1) RFTCTemp2000A: Wireless Thermocouple Temperature Data Logger

(1) Type K Thermocouple

(1) Glycol Bottle (optional)

(1) Power Supply

The VTMS is a wireless temperature data logging system specifically designed to continuously monitor temperature-sensitive vaccines/pharmaceuticals in refrigerators, freezers and coolers. Without the optional glycol bottle, the VTMS can measure and record temperatures as low as -100 °C (-148 °F).

This device features an LCD screen which provides instant access to current readings, minimum, maximum and average statistics. Equipped with user-programmable alarms, the VTMS will alert or notify users via email or text when thresholds are breached, allowing users to take immediate action. For refrigeration storage, the RFTCTemp2000A connects to a glycol bottle, providing temperature buffered readings.

The VTMS is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

The VTMS is also MadgeTech Cloud Services ready, providing users the ability to monitor data remotely on any smartphone, tablet or internet enabled device.

• Wireless Two-Way Communication

• Type K Thermocouple Included

• Optional Glycol Bottle

• Ambient and Thermocouple

• Temperature Monitoring

• View Data in Real time

• 3 Year Battery Life

• Battery Life Indicator

• Field Upgradeable

• Audible and LED Alarm Indicators

• Cumulative Alarm Display

• On Screen Min, Max & Average Statistics

Internal Channel Temperature Sensor	Semiconductor
Internal Channel Temperature Range	-20 °C to 60 °C (-4 °F to +140 °F)
Internal Channel Temperature Resolution	0.1 °C (0.18 °F)
Internal Channel Temperature Calibrated Accuracy	±1.0 °C
Remote Channel Temperature Sensor	Type K Thermocouple (Included)
Memory	16,128 readings per channel
Reading Rate	1 reading every second up to 1 reading every 24 hours
Baud Rate	250,000
Cold Junction Compensation	Automatic based on internal channel
Battery Life	3 years typical at 1 minute reading rate
Material	ABS Plastic
Dimensions	3.0 in x 3.5 in x 0.95 in (76.2 mm x 88.9 mm x 24.1 mm) - Data logger only
Operating Environment	-20 °C to +60 °C (-4 °F to +140 °F), 0 %RH to 95 %RH non-condensing
Required Interface Package	RFC1000 (wireless); USB to Mini USB Cable
Approvals	US (FCC), CA (IC), CE, South Korea (KCC), China (CMIIT), Japan (LCIE)

• Laboratories and hospitals
• Vaccine temperature monitoring
    - Refrigerators
    - Freezers
• Medical and pharmaceutical monitoring
• Process verification and validation
